| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | CABLE COMP,THROT | 17910KVB904 |
|
| 2 | SUB CORD FR STOP SW | 32101KVBN60 |
|
| 3 | SWITCH UNIT LIGHTING | 35150KWWA01 |
|
| 4 | SWITCH UNIT START | 35160KWWA01 |
|
| 5 | SWITCH UNIT DIMMER | 35170KWWA01 |
|
| 6 | SWITCH UNIT HORN | 35180KWWA01 |
|
| 7 | SWITCH UNIT WINKER | 35200KWWA01 |
|
| 8 | SWITCH ASSY FR STOP | 35340KPH901 |
|
| 8 | SWITCH ASSY FR STOP | 35340GZ9003 |
|
| 8 | SWITCH ASSY FR STOP | 35340K81N31 |
|
| 9 | CABLE COMP,FR BRK CONN. | 43440KVB920 |
|
| 10 | CABLE COMP., RR BRAKE | 43450KVBN60 |
|
| 11 | CLAMPER RR BRAKE CABLE | 43455KVB900 |
|
| 12 | GRIP COMP THROT | 53140KVB900 |
|
| 13 | GRIP L HDL | 53166KVB900 |
|
| 14 | HOUSING UP THROT | 53167KFM900 |
|
| 15 | HOUSING UND THROT | 53168KFM900 |
|
| 16 | BRACKET,L BRAKE LEVER | 53172KCWJ10 |
|
| 17 | BAND HDL BRACKET | 53173KVB920 |
|
| 18 | COVER,L BRK LEVER BRKT | 53174KVB920 |
|
| 19 | BOOT,BRK LEVER ROD | 53176GBL870 |
|
| 20 | LEVER L STRG HANDLE | 53178KVBN60 |
|
| 21 | EQUALIZER COMP | 53184KCWJ10 |
|
| 22 | ARM COMP,RR BRK LOCK | 53185KVB920 |
|
| 23 | COVER,RR BRK LOCK LEVER | 53186GBL870 |
|
| 24 | SPG,BRK LOCK ARM RETURN | 53188KVB920 |
|
| 25 | CAP LOCK NUT | 88114KVB900 |
|
| 28 | SCREW,HNDL LEVER PIVOT | 90115GBL870 |
|
| 29 | SCREW,HNDL LEVER PIVOT | 90115147000 |
|
| 30 | SCREW,PAN,5X13 | 90117MN5000 |
|
| 31 | NUT,U,5MM | 90302KVBT01 |
|
| 32 | NUT, LOCK | 90314KVB900 |
|
| 33 | BOLT WASHER 6X20 | 934010602000 |
|
| 34 | SCREW PAN 5X12 | 93500050120H |
|
| 35 | SCREW,PAN 5X25 | 93500050250A |
|
| 36 | MIRROR ASSY R BACK BM | 88110KVB930ABM | - |
| 36 | MIRROR ASSY R BACK SR | 88110KVB930CSR |
|
| 36 | MIRROR ASSY R BACK FROZE | 88110KVB930FBM |
|
| 36 | MIRROR ASSY R BACK BK | 88110KVB930FMB |
|
| 36 | MIRROR ASSY R BACK JAZZY | 88110KVB930JGM |
|
| 36 | MIRROR ASSY R BACK PRL | 88110KVB930PFW |
|
| 36 | MIRROR ASSY R BACK PWD | 88110KVB930PPM |
|
| 36 | MIRROR ASY R BACK SPRT | 88110KVB930SBM |
|
| 36 | MIRROR ASSY R BACK STARL | 88110KVB930SSM |
|
| 36 | MIRROR ASSY R BACK WINNI | 88110KVB930WRD |
|
| 37 | MIRROR ASSY L BACK BM | 88120KVB930ABM |
|
| 37 | MIRROR ASSY L BACK SR | 88120KVB930CSR |
|
| 37 | MIRROR ASSY L BACK FROZE | 88120KVB930FBM |
|
| 37 | MIRROR ASSY L BACK BK | 88120KVB930FMB |
|
| 37 | MIRROR ASSY L BACK JAZZY | 88120KVB930JGM |
|
| 37 | MIRROR ASSY L BACK PRL | 88120KVB930PFW |
|
| 37 | MIRROR ASY L BACK PWD | 88120KVB930PPM |
|
| 37 | MIRROR ASY L BACK SPRT | 88120KVB930SBM |
|
| 37 | MIRROR ASSY L BACK STARL | 88120KVB930SSM |
|
| 37 | MIRROR ASSY L BACK WINNI | 88120KVB930WRD |
|
