| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | STAY ENG HARN CLAMP | 11335KVB900 |
|
| 2 | PUMP ASSY WATER | 19200KVBN50 |
|
| 3 | IMPELLER WATER PUMP | 19215KVBT00 |
|
| 4 | GASKET STATOR BASE | 19216KVB900 |
|
| 5 | SEAL MECHANICAL | 19217MAL300 |
|
| 6 | COVER WATER PUMP | 19221KVBN50 |
|
| 7 | CHAIN WATER PUMP DRIVE DI | 19225KVB901 |
|
| 8 | GASKET WATER PUMP COVER | 19226KVB900 |
|
| 9 | SPROCKET WATER PUMP DRIVE | 19232KVB900 |
|
| 10 | SHAFT COMP W/P | 19240KVB900 |
|
| 11 | THERMOSTAT ASSY | 19300KVB901 |
|
| 12 | O-RING | 19381KVB900 |
|
| 13 | PIPE B WATER | 19422KVB900 |
|
| 14 | CLIP RING | 19505KVB900 |
|
| 15 | CLAMP A ACG CORD | 32961KVB900 |
|
| 16 | WASHER SEALING 6.5MM | 90463ML7000 |
|
| 17 | CABLE,STRAP | 90672SA0003 |
|
| 18 | OIL SEAL,20.8X32X6 | 91201KWN902 |
|
| 19 | OIL SEAL 12X24X 5 | 91203436004 |
|
| 20 | O-RING,12.5X2.4 | 91301KVB900 |
|
| 21 | PIN DOWEL 8X10 | 9430108100 |
|
| 22 | 957010601801 | 957010601800 | - |
| 23 | BOLT FLANGE 6X25 | 957010602500 |
|
| 24 | BOLT FLANGE 6X30 | 957010603000 |
|
| 25 | BOLT FLANGE 6X35 | 957010603500 |
|
| 26 | BOLT FLANGE 6X55 | 957010605500 |
|
| 27 | BOLT FLANGE 6X20 | 960010602000 |
|
