| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | SWITCH FR STOP ASSY | 35340MGSD31 |
|
| 1 | SWITCH FR STOP ASSY | 35340KWB601 |
|
| 2 | HOSE COMP A, FR BRK | 45126K2SN11 |
|
| 3 | HOSE COMP B, FR BRK | 45127K2SN11 |
|
| 4 | CLAMPER COMP A,BRAKE HOSE | 45156K2SN10 |
|
| 5 | CLAMPER B,BRAKE HOSE | 45157K2SN10 |
|
| 6 | BOOT COMP | 45504410003 |
|
| 7 | SUB ASSY,FR M/C | 45510K2SN11 |
|
| 8 | PROTECTOR | 45512MA6006 |
|
| 9 | CAP,MASTER CYL | 45513HA2006 |
|
| 10 | HOLDER, MIRROR | 45517K81N30 |
|
| 11 | DIAPHRAGM | 45520GE2006 |
|
| 12 | PLATE DIAPHRAGM | 45521K21901 |
|
| 13 | CYLINDER SET.FR M | 45530KVSM21 |
|
| 13 | CYLINDER SET, MASTER | 45530K03M61 |
|
| 14 | STAY, ABS MOD | 50322K2SN10 |
|
| 15 | LEVER, R. STEERING HANDLE | 53175KPNE01 |
|
| 16 | MODULATOR ASSY | 57110K2SN11 |
|
| 17 | BOLT FLANGE 6MM | 90111162000 |
|
| 18 | BOLT OIL, 10X22 (NISSIN) | 90145KPHB30 |
|
| 19 | BOLT HANDLE LEVER | 90114KGH900 |
|
| 19 | BOLT OIL 10X22 | 90145GAZ981 |
|
| 20 | WASHER OIL BOLT | 90545300000 |
|
| 21 | CIRCLIP, INTERNAL, 18.8 | 90651K03M61 |
|
| 22 | SCREW FLAT, 4X12 | 93600040121G |
|
| 23 | SCREW WASHER 4X12 | 938930401217 |
|
| 24 | NUT,FLANGE 6MM | 9405006000 |
|
| 25 | BOLT FLANGE 6X12 | 957010601200 |
|
| 26 | BOLT FLANGE 6X22 | 960010602207 |
|
| 26 | BOLT FLANGE 6X22 | 960010602200 |
|
