| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | OIL PUMP ASSY | 15100KGH900 | - |
| 2 | GEAR,OIL PUMP DRV | 15131KEH900 | - |
| 3 | ROTOR,OIL PUMP IN | 15331399000 | - |
| 4 | ROTOR,OIL PUMPOUT | 15332399000 | - |
| 5 | ROTOR OIL FILTER | 15430440030 |
|
| 6 | CAP,ROTOR FILTER | 15436107000 |
|
| 7 | OIL,THROUGH | 15441KCS650 |
|
| 8 | SPRING OIL.GUIDE | 15446107000 |
|
| 9 | GASKET OIL FILTER CAP ROTOR | 15459107000 |
|
| 10 | GEAR,PRIMARY DRV | 23121KCN000 |
|
| 11 | SCREW FLAT 6X30 | 90101440001 | - |
| 12 | NUT,LOCK 16MM | 90231KCS651 | - |
| 13 | WASHER,16MM | 90434KN6931 | - |
| 14 | O-RING,9.4X2.4 | 91304KK3830 |
|
| 15 | BOLT HEX 5X20 | 92101050200A |
|
| 16 | SCREW FLAT 4X12 | 93600040120G | - |
| 17 | SCREW OVAL 5X12 | 93700050120A |
|
| 18 | PIN LOCK 8MM | 9425108000 |
|
