| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | SEALSET,PISTON | 06451GE2405 |
|
| 2 | PAD SET | 06455KR3404 |
|
| 3 | SCREW,BLEEDER | 43352568003 |
|
| 4 | CAP,BLEEDER | 43353461771 |
|
| 4 | CAP,BLEEDER | 43353461772 |
|
| 5 | PISTON | 45107MN5006 |
|
| 6 | SPRING,PAD | 45108ML4006 |
|
| 7 | PIN,BOLT | 45131GZ0006 |
|
| 8 | BUSH PIN | 45132166016 |
|
| 9 | BOOT B,PIN | 45133MA3006 |
|
| 9 | BOOT B,PIN | 45133MA3007 |
|
| 10 | PLUG,PIN | 45203MG3016 |
|
| 11 | PIN,HANGER | 45215KA3732 |
|
| 12 | WASHER,WAVE | 45216166006 |
|
| 13 | CALIPER ASSY R. FR BRAKE | 45200KTM852 |
|
| 14 | BRACKET SUB ASSY R | 45290KEV651 | - |
| 15 | BOLT TORX 8X25 | 90131KPH880 |
|
