| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | SWITCH UNIT LIGHTING | 35150KPH880 |
|
| 2 | SWITCH UNIT START | 35160KPH881 |
|
| 3 | SWITCH UNIT DIMMER | 35170KPH651 |
|
| 4 | SWITCH UNIT HORN | 35180KPH881 |
|
| 5 | SWITCH UNIT WINKER | 35200KPH901 |
|
| 6 | Rubber Main Step Mounting | 50613KFL850 |
|
| 7 | PIPE COMP STRG HANDLE | 53100KTM850 |
|
| 8 | WEIGHT B ASSY STRG HDL(Y) | 53104KPH720 | - |
| 9 | WEIGHT A STRG HDL(Y) | 53105KPH720 |
|
| 10 | RUBBER A HANDLE WEIGHT | 53106KR3000 |
|
| 11 | RING HDL WHT SNAP | 53108KR3770 |
|
| 12 | COLLAR HDL MOUNTING | 53109KPH900 |
|
| 13 | POST COMP HDL | 53120KTM950 |
|
| 13 | POST COMP HDL | 53120KTM860 |
|
| 14 | COVER HDL FR(PF WH) | 53205KPH700FMX | - |
| 14 | COVER HDL FR(BLACK) | 53205KPH700FMB | - |
| 14 | COVER HDL FR (TPBLU) | 53205KPH700FMT |
|
| 14 | COVER HDL FR (PB ORG) | 53205KPH700FMR |
|
| 16 | COVER SPEEDOMETER(SLV) | 53207KPH700 | - |
| 17 | PIN SCREEN SETTING | 64206GT4001 |
|
| 18 | NUT SPEED 4 MM | 64206MJ0001 |
|
| 19 | NUT CLIP 4MM | 64521MN5000 |
|
| 20 | BOLT FR HANDLE COVER | 90103KPH721 |
|
| 21 | BOLT FLANGE 10X50 | 90106GN5900 |
|
| 23 | NUT U10MM | 90304KGH901 |
|
| 24 | COLLAR A HDL SET | 90501KPH690 |
|
| 25 | COLLAR B HDL SET | 90505KPH880 |
|
| 26 | SCREW PAN 5X11.5 | 91509GE2760 |
|
| 27 | BOLT HEX 8X25 | 92101080250A |
|
| 28 | SCREW WASHER 4X16 | 938910401607 | - |
| 29 | SCREW WASHER 4X20 | 938910402008 | - |
| 30 | VISOR SPEEDOMETER SET | 64110KTM5A0 | - |
| 32 | RUBBER CAP B HDL RR COVER | 53208KPH700 | - |
| 33 | RUBBER CAP A HDL RR COVER | 53209KPH700 |
|
