| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | RUBBER BODY CVR SETTING | 64415KPHB30 |
|
| 2 | KEY SET | 35010KTM850 | - |
| 2 | KEY SET | 35010KTM780 |
|
| 3 | 35011KTL750 | 35011KTL750 | - |
| 4 | 35121KPH690 | 35121KPH690 | - |
| 5 | FRAME BODY | 50100KTM850 | - |
| 6 | STAY FR TOP COVER ASSY | 6422AKTM850 | - |
| 7 | SOCKET BOLT 6X10 | 90106KPH690 |
|
| 8 | SCREW LOCK /K4 | 90164028000 |
|
| 9 | NUT FLANGE 10MM | 9405010080 |
|
| 10 | BOLT FLANGE 8X32 | 957010803200 |
|
| 11 | BOLT FLANGE 10X110 | 958011011008 |
|
| 13 | CLIP, HARNESS BAND | 91540KPH902 |
|
