| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | COIL ASSY IGN | 30510KPH701 | - |
| 2 | SPACER IGNITION C | 30520ML7000 | - |
| 3 | CAP ASSY NOISE SUPPRESSOR | 30700KPH881 |
|
| 4 | REG RECT COMP | 31600KPH701 |
|
| 5 | HARNESS WIRE | 32100KTM780 |
|
| 6 | SUB HARNESS SPEEDOMETER | 32101KTM780 |
|
| 7 | SUB HARNESS BATTERY | 32103KTM780 |
|
| 8 | CABLE STARTER MOTOR | 32410KPH900 |
|
| 9 | DUMMY,WPC 4P 090 M (RED) | 32606GEV761 |
|
| 10 | RUBTAIL/LT BRKT. | 33714KL3620 |
|
| 11 | SENSOR ASSY, BANK ANGLE | 35160KPH701 | - |
| 13 | GROMMET | 35163MN5003 |
|
| 14 | CLAMP | 37215KR1760 | - |
| 15 | HORN COMP (HIGH) | 38110KTM851 |
|
| 16 | COLLAR HORN SETTING | 38117KPH880 |
|
| 17 | RELAY ASSY WINKER | 38300KPH881 |
|
| 18 | RELAY COMP WINKER | 38301KPH881 |
|
| 19 | SUSPENSION RELAY | 38306KK4000 |
|
| 20 | RELAY COMP START | 38501KPH901 |
|
| 21 | PGM-FI UNIT | 38770KTM781 |
|
| 22 | CLIP, PIPE | 90661KPH701 | - |
| 23 | BOLT HEX 6X20 | 92101060204J |
|
| 24 | SCREW WASHER 4X20 | 938910402007 | - |
| 25 | SCREW TAPPING 4X10 | 9390324210 |
|
| 26 | BOLT FLANGE 6X14 | 957010601400 |
|
| 27 | BOLT FLANGE 6X20 | 957010602000 |
|
| 28 | FUSE, BLADE (10A) | 9820031000 | - |
| 29 | BLADE FUSE 15A | 9820031500 |
|
