| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | CABLE COMP THROTTLE | 17910KTM850 |
|
| 1 | CABLE COMP, THROT | 17910KTM780 |
|
| 2 | CABLE COMP, CHOKE | 17950KFLD00 |
|
| 3 | LEVER CHOKE | 17961KFM900 |
|
| 4 | STOPPER CABLE | 17962KTM850 |
|
| 5 | 53140KPH880 | 53140KPH880 | - |
| 6 | GRIP L HDL | 53166KET900 |
|
| 7 | HOUSING UP THROT | 53167KFM900 |
|
| 8 | HOUSING UND THROT | 53168KFM900 |
|
| 9 | CAP LOCK NUT | 88113KET900 | - |
| 10 | 88210KTMN00ZA | 88210KTMN00ZA | - |
| 10 | 88210KTMN00ZB | 88210KTMN00ZB | - |
| 10 | 88210KTMN00ZC | 88210KTMN00ZC | - |
| 10 | 88210KTMN00ZD | 88210KTMN00ZD | - |
| 10 | 88210KTMN00ZE | 88210KTMN00ZE | - |
| 11 | 88220KTMN00ZA | 88220KTMN00ZA | - |
| 11 | 88220KTMN00ZB | 88220KTMN00ZB | - |
| 11 | 88220KTMN00ZC | 88220KTMN00ZC | - |
| 11 | 88220KTMN00ZD | 88220KTMN00ZD | - |
| 11 | 88220KTMN00ZE | 88220KTMN00ZE | - |
| 12 | NUT LOCK | 90314KVR600 |
|
| 13 | WASHER PLAIN | 90441147000 |
|
| 14 | WASHER WAVE | 90442147000 |
|
| 15 | SCREW PAN /M | 93500050120A |
|
| 16 | SCREW PAN 5X12 | 93500050120G |
|
| 17 | SCREW,PAN 5X28 | 93500050280A | - |
| 18 | NUT LOCK | 90314KVR600 |
|
