| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | SWITCH UNIT LIGHTING | 35150KPH880 |
|
| 2 | SWITCH UNIT START | 35160KPH881 |
|
| 3 | SWITCH UNIT DIMMER | 35170KPH651 |
|
| 4 | SWITCH UNIT HORN | 35180KPH881 |
|
| 5 | SWITCH UNIT WINKER | 35200KPH901 |
|
| 6 | PIPE COMP STRG HANDLE | 53100KTL740 |
|
| 7 | PIPE COMP STRG HANDLE | 53100KTL750 |
|
| 8 | WEIGHT B STRG HDL | 53104KPH950 | - |
| 9 | WEIGHT A STRG HDL | 53105KPH950 |
|
| 10 | RUBBER A HANDLE WEIGHT | 53106KR3000 |
|
| 10 | RING HDL WHT SNAP | 53108KR3770 |
|
| 11 | 53206KTL690 | 53206KTL690 | - |
| 12 | COVER HDL FR(BLK)DR | 53205KTL690FMB | - |
| 12 | 53205KTL690FMH | 53205KTL690FMH | - |
| 12 | COVER HDL FR(TPBL)DR | 53205KTL690FMT |
|
| 12 | COVER HDL FR(BLK)DK | 53205KTL700FMB | - |
| 13 | NUT CLIP 4MM | 64521MN5000 |
|
| 14 | BOLT FR HDL COVER(Y) | 90103KPH721 |
|
| 15 | BOLT FLANGE 10X50 | 90106GN5900 |
|
| 16 | 90191KPP900 | 90191KPP900 | - |
| 17 | NUT U10MM | 90304KGH901 |
|
| 18 | COLLAR A HDL SET | 90501KPH880 |
|
| 19 | COLLAR B HDL SET | 90505KPH880 |
|
| 20 | SCREW PAN 5X11.5 | 91509GE2760 |
|
| 21 | SCREW WASHER 4X16 | 938910401608 |
|
| 22 | SCREW WASHER 4X20 | 938910402007 | - |
| 23 | SCREW TAPPING 4X12 | 9390334380 |
|
