| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | MAINSHAFT 12T | 23211KFM902 | - |
| 2 | COUNTERSHAFT | 23221KFL860 |
|
| 3 | GEAR C-1 34T | 23421KEV901 | - |
| 4 | BUSH 20X9 | 23422GB4771 | - |
| 5 | GEAR M-2 17T | 23431KEV911 | - |
| 6 | GEAR C-2 29T | 23441KEV901 | - |
| 7 | GEAR M-3 21T | 23451KFL852 | - |
| 8 | GEAR C-3 26T | 23461GK4763 | - |
| 9 | 23471KEV750 | 23471KEV750 | - |
| 10 | GEAR C-4 23T | 23481GB4772 | - |
| 11 | SPROCKET DRIVE 14T | 23801GF6002 |
|
| 12 | PLATE FIXING | 23802GN5911 |
|
| 13 | COLLAR LOCK PLATE | 23911GB4771 | - |
| 14 | SPRING CHANGE FRICTION | 24305GB4771 | - |
| 15 | PLATE DRUM LOCK | 24306GB4771 | - |
| 16 | WASHER THRUST 17MM | 90452GB4771 |
|
| 17 | WASHER SPLINE 20X1.2 | 90461GB4771 |
|
| 18 | WASHER SPLINE 17MM | 90461035003 |
|
| 19 | WASHER SPLINE 20MM | 90461459010 |
|
| 20 | CIRCLIP EXTERNAL 17MM | 90601001005 |
|
| 23 | 91203GB5762 | 91203GB5762 | - |
| 23 | 92101060100A | 92101060100A |
|
| 25 | BEARING RADIAL BALL 6001 | HB6001 |
|
| 26 | BEARING RADIAL BALL6201 | HB6201 |
|
| 27 | BEARING RADIAL BALL 6203 | HB6203 |
|
