| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | 38521K0G950 | 38521K0G950 | - |
| 2 | FORK ASSY R FRONT | 51400K0GT21 | - |
| 2 | 51400K0GD21 | 51400K0GD21 | - |
| 3 | SPRING FR FORK | 51401K0GT21 | - |
| 4 | PIPE COMP FR FORK | 51410K0GT21 | - |
| 5 | SPG REBOUND | 51412GN5901 |
|
| 6 | RING BACK UP | 51412KWB601 |
|
| 7 | CASE COMP R FR BO | 51420K0G901 | - |
| 7 | 51420K0G951 | 51420K0G951 | - |
| 8 | DUST SEAL FR FORK | 51425GN5901 |
|
| 9 | RING PISTON | 51437KWB601 |
|
| 10 | SEAT B,SPRING | 51454K58TC1 |
|
| 11 | RIMG,STOPPER | 51456KPH901 |
|
| 12 | RING OIL SEAL | 51466065901 |
|
| 13 | PIPE SEAT | 51470K0GT21 | - |
| 14 | SEAL SET FR FORK | 51490KGH901 |
|
| 15 | FORK ASSY L FRONT | 51500K0GT21 | - |
| 16 | CASE COMP L FR BO | 51520K0G901 | - |
| 17 | SPECIAL SCREW 5MM | 90102MEJJ00 | - |
| 18 | BOLT,SOCKET 8MM | 90116KV3701 |
|
| 19 | WASHER SPECIAL (8MM) | 90544283000 |
|
| 20 | O-RING,FR FORK | 91256166003 |
|
