| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | PIPE COMP,STRG HANDLE | 53100K3VN00 |
|
| 2 | COVER, HNDL END | 53102K0LD00 | - |
| 3 | COVER,HANDLE FR (MT GN BL) | 53205K3VN10ZB |
|
| 3 | COVER,HANDLE FR (MA PR CR) | 53205K3VN10ZC |
|
| 3 | COVER,HANDLE FR (CI GR MT) | 53205K3VN10ZD |
|
| 3 | COVER,HANDLE FR (VI BE) | 53205K3VN00ZA |
|
| 3 | COVER,HANDLE FR (AB RD MT) | 53205K3VN00ZB |
|
| 3 | COVER,HANDLE FR (AS BK MT) | 53205K3VN00ZC |
|
| 4 | COVER,HANDLE RR | 53206K3VN00ZA |
|
| 5 | COVER,METER (MT CR SL) | 53208K3VN00ZB |
|
| 5 | COVER,METER (MA AX GY) | 53208K3VN00ZA |
|
| 6 | COVER,HEAD LIGHT | 53209K3VN10 |
|
| 6 | COVER,HEAD LIGHT (MT CR SL) | 53209K3VN00ZA |
|
| 7 | Garnish Handle Cover Rear (VI BE) | 53207K3VN00VBE |
|
| 7 | Garnish Handle Cover Rear (MA PR CR) | 53207K3VN00MPC |
|
| 7 | Garnish Handle Cover Rear (MT GN BL) | 53207K3VN00MGB |
|
| 7 | Garnish Handle Cover Rear (AB RD MT) | 53207K3VN00ARE |
|
| 7 | Garnish Handle Cover Rear (CI GR MT) | 53207K3VN00CGM |
|
| 7 | Garnish Handle Cover Rear (AS BK MT) | 53207K3VN00ASB |
|
| 8 | GROMMET,SIDE COVR | 83551376000 |
|
| 9 | EMBLEM, WING MARK | 86150KPG901 |
|
| 9 | EMBLEM,PRODUCT (UEHARA) | 86150KPG902 |
|
| 9 | EMBLEM,PRODUCT | 86150KTJC60 |
|
| 10 | BOLT FLANGE DR 10X48 | 90102KZL930 |
|
| 11 | RIVET PUSH 6MM | 90116K0AE11 |
|
| 12 | RIVET,PUSH | 90116K0WNA1 |
|
| 12 | RIVET,PUSH 6MM | 90116K3VN01 |
|
| 13 | SCREW,SPECIAL 6MM | 90164K66V00 |
|
| 14 | NUT SPRING 4MM | 90302KWWA00 |
|
| 15 | NUT U10MM | 90304KGH901 |
|
| 16 | COLLAR A HDL SET | 90501KPH880 |
|
| 17 | COLLAR B HDL SET | 90505KPH880 |
|
| 18 | CLIP SNAP FIT(PO) | 90666K59A11 |
|
| 19 | SCREW TAPPING 4X12 | 9390324380 |
|
| 20 | SCREW, TAPPING, 4X16 | 9390324480 |
|
| 21 | SCREW TAPPING 5X16 | 9390335320 |
|
