F-14 Floor Steep – Katalog Suku Cadang Honda SH150i

Gambar Bagian

Section Image Section Image

Daftar Suku Cadang

# Nama Part Nomor Part Gambar
1 CUSHION C, BATTERY 50387KZL930 -
2 STEP FLOOR 64311K77V00ZA -
3 COVER CENTER 64312K77V00ZA -
4 LID MAINT 64314K77V00ZA -
5 LID RES TANK 64315K77V00ZA -
6 HOLDER BATTERY 64316K78U00 -
6 HOLDER BATTERY 64316K77V00 -
7 STAY FUSE BOX 64317K01900 -
8 COVER BATTERY LOW 64317K77V00ZA -
9 SEAL MAINT LID 64318K77V00 -
10 COVER R FLOOR 64321K77V00ZJ -
10 COVER R FLOOR 64321K77V00ZE -
10 COVER R FLOOR 64321K77V00ZX -
10 COVER R FLOOR 64321K77V00ZE -
10 COVER R FLOOR 64321K77V00ZG -
10 COVER R FLOOR 64321K77V00ZV -
11 COVER L FLOOR 64322K77V00ZJ -
11 COVER L FLOOR 64322K77V00ZA -
11 COVER L FLOOR 64322K77V00ZX -
11 COVER L FLOOR 64322K77V00ZB -
11 COVER L FLOOR 64322K77V00ZG -
11 COVER L FLOOR 64322K77V00ZV -
12 COVER UNDER 64331K77V00 -
13 90116K2PV61 90116SP0003 90116K2PV61
14 NUT SPRING 4MM 90302KWWA00 NUT SPRING 4MM
15 NUT CLIP 5MM. 90677KANT00 NUT CLIP 5MM.
16 BOLT WASHER 6X12 934040601200 BOLT WASHER 6X12
17 BOLT WASHER 6X20 934040602007 BOLT WASHER 6X20
18 SCREW-WASHER 5X10 938910501008 -
19 SCREW TAPPING 4X16 9390334480 SCREW TAPPING 4X16
