| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | CRANKCASE COMP R | 11100KZR601 |
|
| 2 | RUB.BUSH,ENG.HANGER | 11103KVB930 |
|
| 3 | PLUG,BRG PUSH | 11114KWN900 |
|
| 4 | SPRING, BEARING PUSH | 11116KZR600 |
|
| 5 | PLATE,BRG PUSH | 11117KWN901 |
|
| 6 | BUSH M STAND | 11205GBC300 |
|
| 7 | BASE, STATOR | 11361KWN901 |
|
| 8 | GASKET,STATOR BASE | 11363KWN900 |
|
| 9 | GAUGE OIL LEVEL | 15651K01900 | - |
| 10 | CLAMP ACG CORD | 32961K29910 |
|
| 11 | STAY, ENGINE HARNESS | 32962KZR600 |
|
| 12 | BOLT A STUD 8X2005 | 90031KWN900 |
|
| 13 | BOLT, RADIATOR DISTANCE | 90036KZR600 |
|
| 14 | BOLT DRAIN PLUG 12X15 | 90131883000 |
|
| 15 | DOWEL PIN,SPL 6.3X10X30 | 90702KWN900 |
|
| 16 | OIL SEAL, 20.8X32X6 | 91201K59A11 |
|
| 17 | O-RING, 18X3 | 91307035000 |
|
| 18 | WASHER, DRAIN PLUG, 12MM | 9410912000 |
|
| 19 | PIN DOWEL 8X10 | 9430108100 |
|
| 20 | BOLT FLANGE 6X14 | 957010601400 |
|
| 21 | BOLT FLANGE 6X25 | 957010602500 |
|
| 22 | BOLT FLANGE 6X65 | 957010606500 |
|
| 23 | BOLT FLANGE 6X80 | 957010608000 |
|
| 24 | BOLT FLANGE 6X130 | 957010613000 |
|
| 25 | BOLT FLANGE SH 6X16 | 960010601600 |
|
