| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | CABLE COMP A,THROT | 17910K2FNC1 | - |
| 1 | CABLE COMP A,THROT | 17910K2FND1 | - |
| 2 | CABLE COMP B,THROT | 17920K2FNC1 | - |
| 2 | CABLE COMP B,THROT | 17920K2FND1 | - |
| 3 | BAND B1 WIRE /K5 | 32161404000 |
|
| 4 | SWITCH UNIT, STARTER | 35160K27V01 |
|
| 5 | SW UNIT,DIMMER | 35170K1AN11 |
|
| 6 | SWITCH UNIT, HORN | 35180K47N01 |
|
| 7 | SW UNIT,IDLE | 35190K1AN11 |
|
| 8 | SWITCH UNIT, WINKER | 35200K47N01 |
|
| 9 | SWITCH ASSY., FR. STOP | 35340GZ9003 |
|
| 10 | CABLE COMP,FR BRK CONN. | 43440K2FNC1 | - |
| 11 | CABLE COMP,RR BRK | 43450K2FNC1 | - |
| 12 | CLAMPER A,RR BRK CABLE | 43455K1AN80 | - |
| 13 | CLAMPER B,RR BRK CABLE | 43456K1AN80 | - |
| 14 | HOLDER,MIRROR | 45517K3MT00 | - |
| 15 | GRIP COMP,THROT | 53140K2FNC0 | - |
| 16 | GRIP, L HANDLE | 53166K2FN80 |
|
| 17 | HOUSING UPPER THROTTLE | 53167K66V00 |
|
| 18 | HOUSING,UND THROT | 53168K1AN80 | - |
| 19 | BRACKET,L BRAKE LEVER | 53172K2FNC0 | - |
| 20 | LEVER, L STRG HANDLE | 53178K2FNC0 | - |
| 21 | EQUALIZER | 53181K2TV30 | - |
| 22 | LEVER COMP,BRAKE LOCK | 53185K2TV30 | - |
| 23 | PIN, BRAKE LOCK LEVER | 53186K2TV30 | - |
| 24 | SPRING BRAKE LOCK ARM RETURN | 53188K81N30 |
|
| 25 | PIN,BRK CABLE STOPPER | 53189K2FNC0 | - |
| 26 | SCREW,HNDL LEVER PIVOT | 90115K2TV30 | - |
| 27 | SCREW,HNDL LEVER PIVOT | 90116K2TV30 | - |
| 28 | NUT,U,5MM | 90302KVBT01 |
|
| 29 | SCREW, PAN, 5X20 | 93500050200A |
|
| 30 | E-RING 3 MM | 9454003010 |
|
| 31 | BOLT FLANGE 6X22 | 960010602200 |
|
