F-20-30 Front Wheel – Katalog Honda Scoopy eSP K2FP

#	Informasi Produk	Visual
1	AXLE RR WHEEL Part Number : `42301KFM900`
2	COLLAR,RR AXLE DIST Part Number : `42620KTR700`
3	VALVE,RIM (INOUE) Part Number : `42753GM9743`
3	VALVE, RIM(LUHAI) Part Number : `42753K1AN81`
3	VALVE,RIM(CHENG SHIN) Part Number : `42753KBN902`
3	VALVE,RIM(TRITON) Part Number : `42753KWF901`
4	COLLAR FR WHEEL SIDE Part Number : `44311KVB910`
5	COLLAR, FR. WHEEL SIDE Part Number : `44312KZR600`
6	WHEEL SUB ASSY,FRONT (MT GR BR) Part Number : `44650K2FNC0ZA`
6	WHEEL SUB ASSY,FRONT (MA AX GY) Part Number : `44650K2FNC0ZB`
6	WHEEL SUB ASSY,FRONT (SH SL MT) Part Number : `44650K2FNC0ZC`
7	TIRE FR TL (100/90-12) Part Number : `44711K93N02`
7	TIRE FR TL (100/90-12) Part Number : `44711K93N03`
8	DISK,FR BRAKE Part Number : `45351K0JN01`
8	DISK,FRONT BRAKE Part Number : `45351K2FNC1`
8	DISK,FR BRAKE Part Number : `45351K2SN01`
8	DISK,FR BRAKE Part Number : `45351K93N01`
9	BOLT BRK DISK 8X24 Part Number : `90105KGH900`
10	NUT,FLG PT 12MM Part Number : `90306K1AN81`
10	NUT,U,12MM Part Number : `90306KGH901`
11	BRG BALL RADIAL 6201U L Part Number : `91052K03N41`
11	BRG,BALL RADIAL 6201U L Part Number : `91052K24903`
11	BEARING RADIAL BALL(6201U L) Part Number : `91052K24904`
11	BEARING, RADIAL BALL, 6201U Part Number : `91052K44V81`
12	DUST SEAL, 21X32X5 Part Number : `91251KZR601`
