| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | RUBBER BUSH,ENGINE HANGER | 11103K0JN00 |
|
| 1 | RUBBER BUSH,ENGINE HANGER | 11103K0JN21 |
|
| 2 | CRANK CASE COMP,LEFT | 11200K1AN80 | - |
| 3 | UNDER RUBBER BUSH REAR | 11203K35J01 |
|
| 3 | UNDER RUBBER BUSH REAR | 11203KVB901 |
|
| 4 | BUSH M STAND | 11205GBC300 |
|
| 4 | BUSH,M STAND | 11205K0JN00 |
|
| 5 | PLATE,MISSION BRG SET | 11208K0JN00 |
|
| 6 | PLUG,BRG PUSH | 11215K3EC00 | - |
| 7 | SPG,BRG PUSH | 11216K0JN00 |
|
| 8 | OIL SEPARATOR COMP | 11320K1AN80 | - |
| 9 | TUBE,DRAIN | 11343KVG900 |
|
| 10 | PLATE,ENG GUARD | 11411K0JN00 |
|
| 11 | PROTECTOR,SPEED SENSOR | 32112K2CV90 | - |
| 12 | BOLT,SPL 8MM | 90001K0JN00 |
|
| 13 | BOLT,STUD CYLN | 90031K0JN00 |
|
| 14 | BOLT SOCKET 6X18 | 90101K29900 |
|
| 14 | BOLT SOCKET 6X18 | 90001KWR000 |
|
| 15 | BOLT DRAIN PLUG 12X15 | 90131883000 |
|
| 16 | WASHER,SEALING 6MM | 90401K0JN00 |
|
| 17 | WASHER,8MM | 90474333000 |
|
| 18 | PIN DOWEL 8X12 | 90702KFM900 |
|
| 18 | PIN,DOWEL SPECIAL8X12 | 90702KVRC00 |
|
| 19 | BRG,BALL RADIAL 6204 | 91003K1AN81 | - |
| 19 | BRG, BALL RADIAL 6204 | 91003K2SN01 |
|
| 19 | BRG,BALL RADIAL 6204 | 91003KZR601 |
|
| 19 | BEARING RADIAL BALL 6204 | 91003KZR602 |
|
| 20 | BRG,BALL RADIAL 6301 | 91005K1AN81 | - |
| 20 | BRG, BALL RADIAL 6301 | 91005K2SN01 |
|
| 20 | BEARING RADIAL BALL 6301 | 91005KZR601 |
|
| 20 | BEARING RADIAL BALL 6301 | 91005KZR602 |
|
| 21 | BRG,BALL RADIAL 6302 | 91008K1AN81 | - |
| 21 | BEARING RADIAL BALL 6302 | 91008KZR601 |
|
| 21 | BEARING RADIAL BALL 6302 | 91008KZR602 |
|
| 22 | OIL SEAL 19.5X31.5X6 | 91202K0JN01 |
|
| 22 | OIL SEAL,19.5X31.5X6 | 91202K2FN01 | - |
| 23 | OIL SEAL 20X32X6 | 91203K35J01 |
|
| 23 | OIL SEAL, 20X32X6 | 91203K50T01 | - |
| 24 | O-RING,6.8X2.0 | 91301K0JN00 |
|
| 25 | O-RING,95X2.0 | 91307K0JN00 |
|
| 26 | WASHER, DRAIN PLUG, 12MM | 9410912000 |
|
| 27 | CLIP, TUBE(C12) | 9500280000 |
|
| 28 | BOLT FLANGE 6X16 | 957010601600 |
|
| 29 | BOLT FLANGE 6X30 | 957010603000 |
|
| 30 | BOLT, FLANGE, 8X12 | 957010801200 |
|
| 31 | BOLT FLANGE 8X18 | 957010801801 |
|
