| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | CONTROL UNIT, ENGINE | 30400K2FN01 |
|
| 2 | COIL COMP., IGNITION | 30510K1AN01 |
|
| 3 | CAP ASSY., NOISE SUPPRESSOR | 30700K1AN01 |
|
| 3 | CAP ASSY., NOISE SUPPRESSOR | 30700K44V81 |
|
| 4 | RECTIFIER ASSY., SILICON | 31700124008 |
|
| 5 | HARNESS, WIRE | 32100K2FN00 |
|
| 6 | SUB HARNESS, FR | 32103K2FN00 |
|
| 7 | SUB HARNESS, ENGINE | 32105K2FN00 |
|
| 8 | CAP, DUMMY(4P)(RED) | 32606GEV761 |
|
| 9 | KEY SET | 35010K1AN00 |
|
| 10 | SWITCH ASSY., COMBINATION & LOCK | 35100K1AN01 |
|
| 11 | SWITCH COMP., COMBINATION & LOCK | 35101K1AN01 |
|
| 12 | SHUTTER, KEY | 35110K1AN01 |
|
| 13 | KEY, BLANK | 35121K1AN00 |
|
| 14 | SWITCH ASSY., SEAT OPENER | 35190K1AN01 |
|
| 15 | COVER, CABLE | 35191K27V01 |
|
| 16 | HORN COMP | 38110K93N01 |
|
| 17 | COLLAR, HORN SETTING | 38112KZLA00 |
|
| 18 | FUSE, BLADE(10A) | 38221SNAA41 |
|
| 19 | FUSE, BLADE(20A) | 38221SNAA61 |
|
| 20 | FUSE, BLADE(5A) | 38221TZ3A01 |
|
| 21 | RELAY COMP. WINKER | 38301KPH881 |
|
| 21 | RELAY COMP. WINKER | 38301GBG911 |
|
| 22 | RELAY COMP. WINKER | 38301KZRC01 |
|
| 22 | RELAY COMP. WINKER | 38301K16901 |
|
| 23 | SUSPENSION, WINKER RELAY | 38306K16901 |
|
| 24 | SUSPENSION, WINKER RELAY | 38306KK4000 |
|
| 25 | COVER, SEAL | 38307K16901 |
|
| 26 | COVER, SEAL | 38307K93N01 |
|
| 27 | CONTROL UNIT, ALARM & ANSWER BACK | 38410K93N01 |
|
| 28 | RELAY ASSY., POWER (MICRO ISO 4P)R(MB) | 38501KVZ631 |
|
| 28 | RELAY ASSY., POWER (MICRO ISO 4P) | 38501KWN901 |
|
| 28 | RELAY ASSY., POWER | 38501MKPDN1 |
|
| 29 | RELAY COMP., POWER(MICRO ISO 5P)(MB) | 38502GGZJ01 |
|
| 29 | RELAY COMP., POWER(MICRO ISO 5P) | 38502K81N01 |
|
| 30 | BUZZER ASSY. | 38720K1WD01 |
|
| 31 | CAP | 38941K2FN01 |
|
| 32 | CHARGER UNIT, USB(TYPE-A) | 38950K2FN01 |
|
| 33 | STAY, ELECTRONIC CONTROL UNIT 1 | 50310K2FN00 |
|
| 34 | RUBBER B, MOUNTING | 61106KW6840 |
|
| 35 | GUIDE, HARNESS | 64333K0JN00 |
|
| 36 | CASE, UPPER | 72146K93N01 |
|
| 37 | TRANSMITTER ASSY., ALARM & ANSWER | 72147K93N02 |
|
| 38 | BATTERY COMP | 72148TY0000 | - |
| 39 | SCREW, SCREEN SETTING | 90101MT4000 |
|
| 40 | BOLT, SPECIAL, 6MM | 90107KVB900 |
|
| 41 | BOLT, SOCKET, 5X9 | 90111MR5000 |
|
| 42 | RIVET, PUSH, 6MM | 90116K0AE11 |
|
| 43 | SCREW, U-LOCK FLAT, 6X12 | 90164KZLA00 |
|
| 44 | CLIP, COUPLER(DARK GRAY) | 91534SWA003 |
|
| 45 | CLIP, COUPLER(DARK BLUE) | 91535STK003 |
|
| 46 | CLIP, COUPLER(DARK BROWN) | 91535TA0003 |
|
| 47 | SCREW, TAPPING, 4X12 | 9390124320 |
|
| 48 | BOLT, FLANGE, 6X12 | 957010601200 |
|
| 49 | BOLT, FLANGE, 6X16 | 957010601600 |
|
| 50 | BOLT, FLANGE, 6X20 | 957010602000 |
|
| 51 | BOLT, FLANGE, 6X22 | 960010602200 |
|
