F38 – Wire Harness – Katalog Honda Revo FI K03

#	Informasi Produk	Visual
1	Coil Comp Ignition Part Number : `30410KVY960`
2	Spacer Ignition Coil Part Number : `30520GFM900`
3	Cap Assy Noise Suppressor Part Number : `30700K03N31`
3	Cap Assy Noise Suppressor Part Number : `30700KWW641`
4	Regulator Rectifier Comp Part Number : `31600KWW641`
5	Harness Wire Part Number : `32100K03N30`
5	Harness Wire Part Number : `32100K03N50`
6	Sub Harness Battery Part Number : `32103K03N30`
7	Band B1 Wire Part Number : `32161KRS600`
8	Dummy WPC 4P 090 M (RED) Part Number : `32606GEV761`
9	Rubber Tail Light Bracket Part Number : `33714KL3620`
10	Horn Comp Part Number : `38110KWWA41`
11	Collar Horn Setting Part Number : `38117KPH880`
12	Relay Comp Start Part Number : `38501KPH901`
12	Relay Comp Start Part Number : `38501KVB901`
13	Suspension Start Relay Part Number : `38506GN5740`
13	Suspension Start Relay Part Number : `38506KWW711`
14	Unit Comp PGM-FI/IGN Part Number : `38770K03N32`
15	Bolt Hex 6X22 Part Number : `90106GFM900`
16	Bolt Flange 6X14 Part Number : `957010601400`
17	Bolt Flange 6X16 Part Number : `957010601600`
18	Fuse Mini 10A Part Number : `9820041000`
20	Fuse Mini 15A Part Number : `9820041500`
