| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | SWITCH ASSY., FR. STOP | 35340MGSD31 |
|
| 1 | SWITCH ASSY., FR. STOP | 35340MA5671 |
|
| 2 | Hose Comp A FR BRK | 45126K1YJ51 |
|
| 2 | HOSE COMP. A, FR. BRAKE | 45126K1ZJ11 |
|
| 3 | HOSE COMP. B, FR. BRAKE | 45127K1ZJ11 |
|
| 3 | Hose Comp B FR BRK | 45127K1YJ51 |
|
| 4 | CLAMPER A, FR. BRAKE HOSE | 45156K97J10 |
|
| 5 | CLAMPER B, FR. BRAKE HOSE | 45157K97J10 |
|
| 6 | CLAMPER C, FR. BRAKE HOSE | 45158K1ZT10 |
|
| 6 | CLAMPER C, FR. BRAKE HOSE | 45158K1ZN50 |
|
| 7 | BOOT COMP | 45504410003 |
|
| 8 | CYLINDER SUB ASSY., FR. BRAKE MASTER | 45510K35V01 |
|
| 9 | PROTECTOR | 45512MA6006 |
|
| 10 | CAP, MASTER CYLINDER | 45513HA2006 |
|
| 11 | HOLDER, MASTER CYLINDER | 45517166006 |
|
| 12 | DIAPHRAGM . | 45520GE2006 |
|
| 13 | PLATE, DIAPHRAGM | 45521K21901 |
|
| 14 | CYLINDER SET, MASTER | 45530471831 |
|
| 14 | CYLINDER SET, MASTER | 45530KET920 |
|
| 15 | STAY, ABS MODULATOR | 50316K97J10 |
|
| 16 | LEVER, R. STEERING HANDLE | 53175KWN901 |
|
| 17 | MODULATOR ASSY | 57110K1ZJ11 |
|
| 18 | BOLT, FLANGE SOCKET, 6X22 | 90101KWN900 |
|
| 19 | BOLT, HANDLE LEVER PIVOT | 90114KGH900 |
|
| 20 | BOLT, OIL, 10X22(NISSIN) | 90145KPHB30 |
|
| 21 | WASHER, OIL BOLT | 90545300000 |
|
| 22 | SCREW, FLAT, 4X12 | 90651MA5671 |
|
| 23 | CIRCLIP | 93600040121G |
|
| 24 | SCREW-WASHER, 4X12 | 938930401217 |
|
| 25 | NUT, FLANGE, 6MM | 9405006000 |
|
| 26 | BOLT, FLANGE, 6X12 | 957010601207 |
|
| 27 | BOLT, FLANGE, 6X12 | 960010601200 |
|
| 28 | BOLT, FLANGE, 6MM | 90111162000 |
|
