| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | BUSH, RR. CUSHION UNDER RUBBER | 11203K35J00 |
|
| 1 | BUSH, RR. CUSHION UNDER RUBBER | 11203K35J01 |
|
| 1 | UNDER RUBBER BUSH REAR | 11203KVB901 |
|
| 2 | COLLAR, RR. WHEEL SIDE | 42311K97T00 |
|
| 3 | COLLAR B, RR. WHEEL SIDE | 42312KVG900 |
|
| 4 | Wheel Comp Rear Brown | 42601K1ZN21MBR |
|
| 4 | WHEEL SUB ASSY., RR. | 42650K1ZN20ZA |
|
| 4 | WHEEL SUB ASSY, RR. (BROWN) | 42650K1ZN20ZB |
|
| 5 | RR.(IRC) (130/70-13) | 42711K1ZN21 |
|
| 6 | VALVE, RIM(IRC) | 42753GM9743 |
|
| 6 | VALVE RIM (PIRELLI) | 42753KBS901 |
|
| 6 | VALVE,RIM(TRITON) | 42753KWF901 |
|
| 7 | DISK, RR. BRAKE | 43251K1ZN21 |
|
| 8 | SWINGARM ASSY., RR | 52100K1ZN20 |
|
| 9 | BOLT, BRAKE DISK, 8X24 | 90105KGH900 |
|
| 10 | NUT, U, 16MM | 90305KVB901 |
|
| 11 | CIRCLIP, INTERNAL, 40MM | 90651KZR601 |
|
| 12 | BEARING, RADIAL BALL, 6203UU L (NSK) | 91051K35V01 |
|
| 12 | BEARING, RADIAL BALL, 6203UU | 91051K35V02 |
|
| 12 | BEARING, RADIAL BALL, 6203UU | 91051K35V03 |
|
| 12 | BEARING, RADIAL BALL, 6203UU | 91051K35V04 |
|
| 13 | DUST SEAL 25X40X5 | 91252K35V01 |
|
| 14 | DUST SEAL 25X35X6 | 91253K35V01 |
|
| 15 | WASHER PLAIN 10MM | 9410110000 |
|
| 16 | BOLT,FLANGE 10X40 | 957011004000 |
|
