| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | SEAL SET,PISTON | 06451MZ2405 |
|
| 2 | PAD SET, FR | 06455KREK02 |
|
| 3 | SCREW,BLEEDER | 43352568003 |
|
| 4 | CAP,BLEEDER | 43353461771 |
|
| 4 | CAP,BLEEDER | 43353461772 |
|
| 5 | PISTON 22 A | 45107KPNE21 |
|
| 6 | PAD SPRING | 45108KPNE21 |
|
| 7 | O-RING,2.5X1.5 | 45111MAJG41 |
|
| 8 | PIN,BOLT | 45131GZ0006 |
|
| 9 | BUSH PIN | 45132166016 |
|
| 9 | BUSH PIN | 45132166017 |
|
| 10 | BOOT B,PIN | 45133MA3006 |
|
| 10 | BOOT B,PIN | 45133MA3007 |
|
| 11 | CALIPER SUB ASSY L FR | 45150K97N01 |
|
| 12 | BRKT SUB ASSY L FR | 45190KSSJ31 |
|
| 13 | PISTON 22 B | 45207KPNE21 |
|
| 14 | PIN HANGER | 45215KPH951 |
|
| 15 | WASHER,WAVE | 45216166006 |
|
| 16 | BOLT, TORX, 8X28 | 90131K97N00 |
|
