| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | SENSOR, FR. WHEEL SPEED | 38520K1ZJ11 |
|
| 1 | SENSOR,WHEEL SPD FR | 38520K1ZJ51 |
|
| 2 | FORK ASSY., R. FR.(SHOWA) | 51400K1Z305 |
|
| 2 | FORK ASSY,R FRONT | 51400K1Z307 |
|
| 3 | SPRING, FR. FORK(SHOWA) | 51401K1ZJ11 |
|
| 4 | COLLAR, SPRING | 51402K97T01 |
|
| 5 | PLATE, SPRING JOINT | 51403KW6961 |
|
| 6 | PIPE COMP., FR. FORK(SHOWA) | 51410K1ZJ11 |
|
| 7 | SPRING, FR. CUSHION REBOUND | 51412GC4003 |
|
| 8 | RING, BACK UP(SHOWA) | 51412KK4003 |
|
| 9 | CASE COMP., R. FR. BOTTOM | 51420K97305 |
|
| 9 | CASE COMP., R. FR. BOTTOM | 51420K1Z305 |
|
| 10 | PIECE, OIL LOCK | 51432KM7910 |
|
| 11 | RING, PISTON | 51437GS3003 |
|
| 12 | SEAT, SPRING UPPER | 51454K1NV01 |
|
| 13 | RING, STOPPER(SHOWA) | 51456355003 |
|
| 14 | PIPE, SEAT(SHOWA) | 51470K1ZJ11 |
|
| 15 | SEAL SET, FR. FORK(SHOWA) | 51490KRM852 |
|
| 16 | FORK ASSY., L. FR.(SHOWA) | 51500K1Z306 |
|
| 16 | FORK ASSY,L FRONT | 51500K1ZN51 |
|
| 16 | FORK ASSY,L FRONT | 51500K1Z305 |
|
| 16 | FORK ASSY,L FRONT | 51500K1Z307 |
|
| 17 | CASE COMP., L. FR. BOTTOM | 51520K97315 |
|
| 17 | CASE COMP,L FR BOTTOM | 51520K97316 |
|
| 17 | CASE COMP,L FR BOTTOM | 51520K1Z305 |
|
| 18 | BOLT, FLANGE, 6X18 . | 90105K77V10 |
|
| 19 | BOLT, SOCKET, 8X27(SHOWA) | 90116383721 |
|
| 20 | WASHER, SPECIAL, 8MM(SHOWA) | 90544283000 |
|
| 21 | RING, OIL SEAL STOP(SHOWA) | 90601354000 |
|
| 22 | DUST SEAL(SHOWA) | 91254GAA003 |
|
| 23 | O RING, 21.8X2.4 | 91356K1NV01 |
|
