| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 2 | TUBE, MISSION BREATHER | 11211K1NV00 |
|
| 3 | CASE COMP., MISSION | 21200K1ZJ10 |
|
| 3 | CASE COMP,MISSION | 21200K2SN10 |
|
| 4 | GASKET, MISSION CASE (NIPPON LEAKLESS) | 21395K1ZJ11 |
|
| 4 | GASKET,MISSION CASE | 21395K1NV01 |
|
| 5 | DRIVESHAFT(18T) | 23411K1ZN20 |
|
| 5 | DRIVESHAFT(18T) | 23411K1ZN30 |
|
| 5 | SHAFT,DRIVE | 23411K0WNA0 |
|
| 6 | COUNTERSHAFT(13T) | 23421K1ZN20 |
|
| 6 | COUNTERSHAFT(13T) | 23421K1ZN30 |
|
| 7 | GEAR, COUNTER(51T) | 23422K1ZN20 |
|
| 7 | GEAR, COUNTER(51T) | 23422K1ZN30 |
|
| 8 | GEAR COMP., FINAL(44T) | 23430K1ZN20 |
|
| 8 | GEAR COMP., FINAL(44T) | 23430K1ZN30 |
|
| 9 | WASHER, SEALING, 8MM | 90495MN5000 |
|
| 10 | BEARING, RADIAL BALL, 6202 (NTN) | 91004KZR601 |
|
| 10 | BEARING, RADIAL BALL, 6202 (FUJIKOSHI) | 91004KZR602 |
|
| 10 | BRG, BALL RADIAL 6202 | 91004K2SN01 |
|
| 11 | BEARING, RADIAL BALL, 6301 (NTN) | 91005KZR601 |
|
| 11 | BEARING, RADIAL BALL, 6301 (FUJIKOSHI) | 91005KZR602 |
|
| 11 | BRG, BALL RADIAL 6202 | 91004K2SN01 |
|
| 11 | BRG,BALL RADIAL 6202 | 91004KZR601 |
|
| 11 | BEARING RADIAL BALL 6202 | 91004KZR602 |
|
| 12 | BEARING, RADIAL BALL, 6205UU (NTN) | 91009KWN901 |
|
| 12 | BRG, BALL RADIAL 6205UU | 91009K2SN01 |
|
| 12 | BEARING, RADIAL BALL, 6205 | 91006KAB004 |
|
| 14 | OIL SEAL, 34X52X7(ARAI) | 91204K35J01 |
|
| 14 | OIL SEAL, 34X52X7(NOK) | 91204K59A11 |
|
| 15 | DOWEL PIN, 10X12 | 9430110120 |
|
| 16 | CLIP, TUBE(C9) | 9500250000 |
|
| 17 | BOLT, FLANGE, 8X45 | 957010804500 |
|
| 18 | BOLT, FLANGE, 8X55 | 957010805500 |
|
