| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | Switch Assy LH Stop | 35340K40F01 |
|
| 2 | Cover LH Stop Switch | 35341K97N00 |
|
| 3 | Hose Comp A,RR Brake CBS | 43311K97N01 |
|
| 4 | Sub Assy RR M/C CBS | 43510K97N01 |
|
| 5 | Boot Comp | 45504410003 |
|
| 6 | Protector | 45512MA6006 |
|
| 7 | Cap Master CYL | 45513HA2006 |
|
| 8 | Holder Master Cylinder | 45517166006 |
|
| 9 | Diaphragm | 45520MG7006 |
|
| 10 | Plate Diaphragm | 45521HA2006 |
|
| 11 | Cylinder Set Master CBS | 45530471831 |
|
| 11 | Cylinder Set Master CBS | 45530KET920 |
|
| 12 | Lever L Handle | 53178K04931 |
|
| 13 | Bolt Flange Socket 6X22 | 90101KWN900 |
|
| 14 | Bolt Handle Lever Pivot | 90114MA5671 |
|
| 15 | Bolt Oil 10x22 Nissin | 90145KPHB30 |
|
| 16 | Washer Oil Bolt | 90545300000 |
|
| 17 | Circlip | 90651MA5671 |
|
| 18 | Screw Flat, 4X12 | 93600040121G |
|
| 19 | Screw Washer 4x12 | 938930401217 |
|
| 20 | Nut Flange 6mm | 9405006000 |
|
