| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | Eng Control Unit | 30400K97N01 |
|
| 2 | Cover Engine Control Unit | 30401K35V00 |
|
| 3 | Coil Comp Ignition | 30510K35V01 |
|
| 3 | Coil Comp Ignition | 30510K35V02 |
|
| 4 | Spacer Ign Coil | 30520GFM900 |
|
| 5 | Cap Assy Noise Suppressor | 30700K97N01 |
|
| 5 | Cap Assy Noise Supressor | 30700KWN981 |
|
| 6 | Harness Wire CBS | 32100K97N00 |
|
| 6 | Harness Wire ABS | 32100K97N10 |
|
| 7 | Sub Harness Engine | 32104K97T00 |
|
| 8 | Cover Acc Socket | 32107K97N00 |
|
| 9 | Dummy WPC 20P 090 | 32605KCWJ91 |
|
| 10 | Dummy WPC 4C 090 M Red | 32606GEV761 |
|
| 11 | Switch Assy Hndl Lock | 35100K97T01 |
|
| 12 | Switch Comp Handle Lock | 35101K97T01 |
|
| 12 | Switch Comp Handle Lock | 35101K97A01 |
|
| 13 | Set Fob Assy | 35121K97N00 |
|
| 13 | Set Fob Assy | 35111K97N02 |
|
| 13 | Set Fob Assy | 35111K97N23 |
|
| 13 | Set Fob Assy | 35111K0WN02 |
|
| 14 | Set, Smart Control Unit | 35141K97N00 |
|
| 14 | Set, Smart Control Unit | 35141K97N32 |
|
| 14 | Set, Smart Control Unit | 35141K97N02 |
|
| 15 | Battery | 35148K78N10 |
|
| 16 | Cover Cable | 35191K53D01 |
|
| 17 | Switch Assy Seat Open | 35193K35V32 |
|
| 18 | Set Emergency Keyng | 35194K35V31 |
|
| 19 | Horn Comp Low | 38120K96V01 |
|
| 20 | Puller Mini Fuse | 38235SNAA01 |
|
| 21 | Cover Comp Upper CBS | 38255K97T01 |
|
| 21 | Cover Comp Upper ABS | 38255K97A11 |
|
| 22 | Relay Comp Led Win | 38301KZZJ01 |
|
| 23 | Relay Comp, Start | 38501KVZ631 |
|
| 23 | Relay Comp Power | 38501KWN901 |
|
| 24 | Relay Comp Power | 38502KWN901 |
|
| 25 | Buzzer Assy Ng Light | 38720K66V11 |
|
| 26 | Mini Fuse 2A | 39214HAC000 |
|
| 27 | Cap Assy | 39602K41N21 |
|
| 28 | Sockewr Assy | 39624K41N21 |
|
| 29 | Screw Opener Set | 90104K53D01 |
|
| 30 | Bolt Spesial 6mm | 90107KVB900 |
|
| 31 | Screw U-Lock Flat 6x12 | 90164KZLA00 |
|
| 32 | Band Wire | 90651KV6003 |
|
| 33 | Clip Coupler (Dark Brown) | 91535TA0003 |
|
| 34 | Clip Wire Harness | 91558SD5003 |
|
| 35 | Bolt Hex 6X20 | 92101060204J |
|
| 36 | Screw Tapp 4x12 | 9390124320 |
|
| 37 | Bolt Flange 6x12 | 957010601200 |
|
| 38 | Bolt Flange 6X16 | 957010601600 |
|
| 39 | Bolt Flange 8X12 | 957010801200 |
|
| 40 | Fuse F (7,5A) | 9820040750 |
|
| 41 | Fuse F (15A) | 9820041500 |
|
| 42 | Fuse Mini (25A) | 9820042500 |
|
