| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | VALVE,RIM (INOUE) | 42753GM9743 |
|
| 2 | AXLE,FR WHEEL | 44301KWN900 | - |
| 3 | COLLAR,FR WHEEL SIDE | 44311KWN900 |
|
| 4 | COLLAR,FR AXLE DIST | 44620KPH950 |
|
| 5 | 44650KWN901ZA | 44650KWN900ZA | - |
| 5 | WHEEL SUB ASSY FR PRSNPB4 | 44650KWN711ZB | - |
| 6 | TIRE FR TL (90/90-14) | 44711KWN901 | - |
| 7 | DISK,FR BRAKE | 45351KVG901 | - |
| 8 | DISK,FR BRAKE | 45351KVG902 | - |
| 9 | BOLT BRK DISK 8X24 | 90105KGH900 |
|
| 10 | NUT,U,12MM | 90306KGH901 |
|
| 11 | BEARING,RADIAL BALL 6201(U) | 91052KVB901 | - |
| 12 | BRG,BALL RADIAL 6201(U) | 91052KVB902 | - |
| 13 | DUST SEAL 21 X 37 X 7 | 91251KPH901 |
|
