| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | Switch FR Stop Assy | 35340KWB601 |
|
| 2 | Hose Comp FR Brake | 45126K25901 |
|
| 3 | Clamper A Brake Hose | 45156KYT900 |
|
| 3 | Clamper A Brake Hose | 45156K50T00 |
|
| 4 | Clamper B Brake Hose | 45157KVBT00 |
|
| 5 | Master Cylinder Assy FR | 45500K25911 |
|
| 5 | Master Cylinder Assy FR | 45500K81N51 |
|
| 6 | Boot Comp | 45504410004 |
|
| 7 | Protector | 45512MA6006 |
|
| 8 | Cap Master Cylinder | 45513GW0911 |
|
| 9 | Holder Master Cylinder | 45517GW0751 |
|
| 11 | Plate Diaphragm | 45521GW0913 |
|
| 12 | Master Cylinder Set | 45530KVY911 |
|
| 12 | Master Cylinder Set | 45530K03M61 |
|
| 13 | Lever R Steering Handle | 53175KVB921 |
|
| 13 | Lever R Steering Handle | 53175K81N51 |
|
| 14 | Spring Return | 53198GBL870 |
|
| 15 | Spring Brake Lever Return | 53199KVG910 |
|
| 16 | BoltHandle Lever | 90114KVG911 |
|
| 17 | Bolt Oil 10X22 (NISSIN) | 90145KPHB30 |
|
| 18 | Washer Oil Bolt | 90545300000 |
|
| 19 | Circlip | 90651MA5671 |
|
| 19 | Circlip Internal 18.8 | 90651K03M61 |
|
| 20 | Screw Flat 4X12 | 93600040121G |
|
| 21 | Screw Washer 4X12 | 938930401217 |
|
| 22 | Nut Flange 6MM | 9405006000 |
|
| 23 | Bolt Flange 6X12 | 957010601200 |
|
| 24 | Bolt Flange 6X14 | 957010601400 |
|
| 25 | Bolt Flange 6X22 | 960010602200 |
|
