| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | Crankshaft Comp | 1300AKZLC30 |
|
| 1 | Crankshaft Comp | 13000K81N00 |
|
| 2 | Ring Set Piston (STD) | 13011K25305 |
|
| 2 | Ring Set Piston (STD) | 13011KVBT00 |
|
| 2 | Ring Set Piston (0,25) | 13021K25305 |
|
| 2 | Ring Set Piston (0.25) | 13012KVBT00 |
|
| 2 | Ring Set Piston (0,50) | 13031K25305 |
|
| 2 | Ring Set Piston (0.50) | 13013KVBT00 |
|
| 2 | Ring Set Piston (0,75) | 13041K25305 |
|
| 2 | Ring Set Piston (0.75) | 13014KVBT00 |
|
| 2 | Ring Set Piston (1,00) | 13051K25305 |
|
| 2 | Ring Set Piston (1.00) | 13015KVBT00 |
|
| 2 | Ring Set Piston (STD) | 13011K25600 |
|
| 2 | Ring Set Piston (STD) | 13011K44V00 |
|
| 2 | Ring Set Piston (0.25) | 13021K25600 |
|
| 2 | Ring Set Piston (0.25) | 13021K44V00 |
|
| 2 | Ring Set Piston (0.50) | 13031K25600 |
|
| 2 | Ring Set Piston (0.50) | 13031K44V00 |
|
| 2 | Ring Set Piston (0.75) | 13041K25600 |
|
| 2 | Ring Set Piston (0.75) | 13041K44V00 |
|
| 2 | Ring Set Piston (1.00) | 13051K25600 |
|
| 2 | Ring Set Piston (1.00) | 13051K44V00 |
|
| 2 | Ring Set Piston (STD) | 13011K81N00 |
|
| 2 | Ring Set Piston (STD) | 13011K93N00 |
|
| 2 | Ring Set Piston (0.50) | 13031K81N00 |
|
| 2 | Ring Set Piston (0.50) | 13031K93N00 |
|
| 2 | Ring Set Piston (0.75) | 13041K81N00 |
|
| 2 | Ring Set Piston (0.75) | 13041K93N00 |
|
| 2 | Ring Set Piston (1.00) | 13051K81N00 |
|
| 2 | Ring Set Piston (1.00) | 13051K93N00 |
|
| 3 | Piston (STD) | 13101K48A00 |
|
| 3 | Piston (0,25) | 13102K48A00 |
|
| 3 | Piston (0,25) | 13102KZL305 |
|
| 3 | Piston (0,50) | 13103KZL305 |
|
| 3 | Piston (0.75) | 13104KZL305 |
|
| 3 | Piston (1.00) | 13105KZL305 |
|
| 3 | Piston (STD) | 13101K48A00 |
|
| 3 | Piston (0,25) | 13102KZL305 |
|
| 3 | Piston (0,50) | 13103K48A00 |
|
| 3 | Piston (0.75) | 13104K48A00 |
|
| 3 | Piston (1.00) | 13105K48A00 |
|
| 3 | Piston (STD) | 13101K81N00 |
|
| 3 | Piston (STD) | 13101K81P00 |
|
| 3 | Piston (0,25) | 13102K81P00 |
|
| 3 | Piston (0,50) | 13103K81P00 |
|
| 3 | Piston (0.75) | 13104K81P00 |
|
| 3 | Piston (1.00) | 13105K81P00 |
|
| 4 | Pin Piston | 13111087001 |
|
| 4 | Pin Piston | 13111KWN900 |
|
| 5 | Clip Pin Piston 13MM | 13115GN5910 |
|
| 6 | Key Woodruff 4MM | 90741KVY900 |
|
| 6 | Key Woodruff 4MM | 90741003010 |
|
