| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | Kit Fuel Filter | 06160K18900 | - |
| 2 | Clip Oil Drain Tube | 15771KV6000 |
|
| 3 | Clip Tube | 15772551000 |
|
| 4 | Pump Assy Fuel | 16700KYE305 |
|
| 5 | Holder Fuel Filter | 16912K18900 |
|
| 6 | Plate Comp L Setting | 17517KYE940 |
|
| 7 | Film Tank Protector | 17519KSPB00 |
|
| 8 | Plate R Setting | 17527K18900 |
|
| 9 | Rubber Shroud Mount | 17529KVN900 |
|
| 10 | Tank Comp Fuel PB-314P | 17530KYE940ZA |
|
| 10 | Tank Comp Fuel R-333C | 17530KYE940ZB |
|
| 10 | Tank Comp Fuel NH-341P | 17530KYE940ZC |
|
| 10 | Tank Comp Fuel NH-1 | 17530KYE940ZD |
|
| 11 | Stay Fuel Filter | 17540KYE940 | - |
| 12 | Tube A Fuel Pump | 17541K18900 | - |
| 13 | Tube B Fuel Pump | 17542K18900 |
|
| 14 | Hose Comp Fuel Feed | 17570KYE940 |
|
| 15 | Gasket Fuel Pump | 17572K15900 |
|
| 16 | Seal Dust | 17573K15900 |
|
| 18 | Cushion FR Fuel Tank | 17611KRY970 |
|
| 19 | Cushion Fuel Tank RR | 17613KSPB00 |
|
| 20 | Cap Fuel Filler Comp | 17620KEH601 |
|
| 21 | Fuel Unit | 37800KYE941 |
|
| 22 | Rubber Side Cover | 83547KSPB00 |
|
| 23 | Bolt Special 6MM | 90101K18900 |
|
| 24 | Collar Fuel Tank Mount | 90324KCJ660 |
|
| 25 | Nut Flange 6MM | 9405006000 |
|
| 26 | Bolt Flange 8X25 | 957010802508 |
|
