| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | CABLE COMP,THROT | 17910KSPB01 |
|
| 2 | CABLE COMP,CHOKE | 17950KSP900 |
|
| 3 | LEVER CHOKE | 17962KCJ690 |
|
| 4 | CABLE COMP,CLUTCH | 22870KYE900 |
|
| 5 | BAND B1 WIRE /K5 | 32161404000 |
|
| 6 | SWITCH ASSY LT ST | 35150KYE901 |
|
| 7 | SWITCH ASSY WINKER | 35200KYE901 | - |
| 8 | SWITCH FR LEVER | 35330413003 |
|
| 9 | HOLDER MASTER CYL | 45517166006 |
|
| 10 | GRIP COMP THROT | 53140KSPA70 |
|
| 11 | GRIP L HDL | 53166KSPA70 |
|
| 12 | BRACKET, HANDLE LEVER | 53172KT7751 |
|
| 13 | LEVER COMP,L HNDL | 53178KYE900 |
|
| 14 | BOOT HDL LEVER | 53180425010 |
|
| 15 | BOLT WIRE ADJ | 53192349690 |
|
| 16 | MIRROR ASSY R BACK | 88110KCJ660 |
|
| 17 | MIRROR ASSY L BACK | 88120KCJ660 |
|
| 18 | BOLT L HDL | 90113438000 |
|
| 19 | NUT,FIXING | 90321MR8000 |
|
| 20 | SCREW,WASHER 5X20 | 938920502007 |
|
| 21 | SCREW,WASHER 5X25 | 938920502507 |
|
| 22 | SCREW WASHER 5X35 | 938920503507 |
|
| 23 | SCREW WASHER 5X45 | 938920504507 |
|
| 24 | NUT,FLANGE 6MM | 9405006000 |
|
| 25 | BOLT FLANGE 6X22 | 960010602207 |
|
