| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | CLAMPER RR BRK HOSE | 43156KSPB00 | - |
| 1 | CLAMPER RR BRK HOSE | 43157KYE940 |
|
| 2 | CLAMPER B RR BRK HO | 43157KSPB00 | - |
| 3 | HOSE COMP, RR BRAKE | 43310KYE901 | - |
| 3 | HOSE COMP, RR BRAKE | 43310KYE941 |
|
| 4 | CONNECTOR, MSTR CYLINDER | 43503MR8006 |
|
| 5 | BOOT COMP | 43504MB2006 |
|
| 6 | SUB ASSY RR M/C | 43510KSPB01 |
|
| 6 | SUB ASSY RR M/C | 43510KYE941 |
|
| 7 | CUP COMP,OIL | 43511KW7881 |
|
| 8 | HOSE COMP RR M/C | 43512KYE941 |
|
| 9 | CAP M/C | 43513KBP881 |
|
| 10 | CLMP,CYLN.OIL | 43514KS6701 |
|
| 11 | PISTON,CYLINDER | 43520MJ6315 |
|
| 12 | PUSH ROD COMP | 43530KS7831 | - |
| 12 | PUSH ROD COMP | 43530KV3701 |
|
| 13 | DIAPHRAGM | 45520GW0911 |
|
| 14 | PLATE,DIAPHRAGM | 45521GW0911 |
|
| 15 | CIRCLIP M/C | 46182MELD21 |
|
| 16 | JOINT BRAKE ROD | 46504KV6702 |
|
| 17 | BOLT FLANGE 6X10 | 90102KGH900 |
|
| 18 | BOLT OIL 10X22 | 90145MS9612 | - |
| 18 | BOLT OIL 10X22 | 90145GAZ981 |
|
| 19 | WASHER OIL BOLT | 90545300000 |
|
| 20 | O-RING,14.8X2.4 | 91212422006 |
|
| 21 | SCREW,FLAT,4X45 | 93600040451G |
|
| 22 | SCREW WASHER 4X12 | 938930401217 |
|
| 23 | NUT,HEX 8MM | 94002080000S |
|
| 24 | NUT,FLANGE 6MM | 9405006080 |
|
| 25 | PIN COTTER 2.0X15 | 9420120150 |
|
| 26 | PIN D JOINT | 9501554000 |
|
| 27 | BOLT FLANGE 6X22 | 957010602208 |
|
