| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | GASKET SET | 16010KSP911 |
|
| 2 | NEEDLE SET JET | 16012KYE901 |
|
| 3 | FLOAT SET | 16013KRC921 | - |
| 4 | 16015KYE901 | 16015KYE901 | - |
| 5 | SCREW SET A | 16016KRP981 |
|
| 6 | SCREW SET B | 16028KPP901 | - |
| 7 | 16037KPP861 | 16037KPP861 | - |
| 8 | VALVE SET,STARTER | 16046KVC901 |
|
| 9 | VALVE SET AIR CUT | 16048KYE901 |
|
| 10 | SPG,COMPRESSION COIL | 16050KGH901 | - |
| 11 | O-RING | 16075KRP981 | - |
| 12 | SCREW WASHER TORX 5X16 | 16080KTN901 | - |
| 13 | CARBURETOR ASSY | 16100KYE902 |
|
| 14 | TOP | 16107KGH902 | - |
| 15 | PISTON COMP VACUUM | 16111KYE305 |
|
| 16 | STAY WIRE | 16119KSP911 | - |
| 17 | BODY COMP BY-ST | 16140KTE911 | - |
| 18 | COVER THROT CABLE | 16150KSPB00 | - |
| 19 | VALVE COMP FLOAT | 16155KFR701 | - |
| 20 | GASKET,FLOATCHAMBER | 16163KGF911 |
|
| 21 | BINDER | 16179KVE901 | - |
| 22 | GASKET,BY-ST | 16423KGH901 |
|
| 23 | SENSOR ASSY THROTTLE | 37890KTN901 | - |
| 24 | SCREW PAN 4X8 | 93500040081H |
|
| 25 | SCREW PAN 4X10 | 93500040101H |
|
| 26 | SCREW PAN 4X12 | 93500040120H |
|
| 27 | SCREW PAN 4X25 | 93500040250G |
|
| 28 | SCREW PAN 5X12 | 93500050121H |
|
| 29 | SCREW WASHER 5X12 | 938920501218 |
|
| 30 | WASHER 4MM | 9410104700 | - |
| 31 | CLIP B8,TUBE | 9500202089 |
|
| 32 | TUBE 4,5X480 | 950054548050 | - |
| 33 | JET 125 | 99101KYE125 |
|
| 34 | JET SLOW 40 | 99103KYE040 |
|
