| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | RUBBER PROTECTOR | 33407KVBT00 |
|
| 2 | GUARD,NUMBER PLATE | 61316K45NL0 |
|
| 3 | STAY COMP FR UPPER COWL | 64150K45NL0 |
|
| 4 | COWL,FR UPPER (NI OR) | 64211K45NL0ZA |
|
| 4 | COWL,FR UPPER (MT GN BL) | 64211K45NL0ZD |
|
| 4 | COWL,FR UPPER (WN RD) | 64211K45NL0ZC |
|
| 4 | COWL,FR UPPER (VA RD) | 64211K45NL0ZB |
|
| 4 | SET ILLUS,FR UPPER COWL TYPE 1 | 64200K45NZ0ZB |
|
| 4 | SET ILLUS,FR UPPER COWL, TYPE 1 | 64200K45A50ZB |
|
| 4 | SET ILLUS,FR UPPER COWL, TYPE 2 | 64200K45A50ZA |
|
| 4 | Set Illus Fr Upper Cowl Type 1 | 64200K45A60ZB |
|
| 4 | Set Illus,FR Upper Cowl Typ 1 | 64200K45NX0ZB |
|
| 5 | WASHER SCREEN SET | 64205166610 |
|
| 6 | COVER,R FRONT SIDE | 64221K45NL0 |
|
| 7 | STAY,NUMBER PLATE | 64222K45NL0 |
|
| 8 | COVER,L FRONT SIDE | 64231K45NL0 |
|
| 9 | SET ILLUS,FR LOWER COWL TYPE 1 | 64240K45NZ0ZA |
|
| 9 | COWL ASSY,FR LOWER (MT GN BL) | 64245K45NL0ZA | - |
| 9 | COWL,FR LOWER (MT GN BL) | 64241K45NL0MGB |
|
| 9 | COWL,FR LOWER (BLK) | 64241K45NL0FMB |
|
| 10 | PANEL METER | 64251K45NL0 |
|
| 11 | SCREEN,WIND | 67111K45NL0 |
|
| 12 | MIRROR ASSY,R BACK | 88110K45NA1 |
|
| 13 | MIRROR ASSY,L BACK | 88120K45NA1 |
|
| 14 | SCREW, SPECIAL, 5MM | 90104KPH900 |
|
| 15 | NUT COWL SET M5X0.8 | 90111KW3003 |
|
| 16 | RIVET PUSH 6MM | 90116K0AE11 |
|
| 17 | BOLT SPECIAL 5X16 | 90119K45N00 |
|
| 18 | BOLT,SOCKET 6X13 | 90130KPPT00 |
|
| 19 | SCREW,PAN 5X14 | 90134KPPT00 |
|
| 20 | NUT,SPRING 5MM | 90320GC3000 |
|
| 21 | NUT HEX CAP | 90443107000 |
|
| 22 | WASHER, THRUST 5MM | 90504964000 |
|
| 23 | PUSH CLIP,AIR INT DUCT | 90601PV3003 |
|
| 24 | CLIP SNAP FIT(PO) | 90666K59A11 |
|
| 25 | NUT CLIP 5MM. | 90677KANT00 |
|
| 26 | CLIP, HARNESS | 90684ZA0601 |
|
| 27 | SCREW TAPPING 4X12 | 9390324380 |
|
| 28 | SCREW, TAPPING, 5X12 | 9390325280 |
|
| 29 | BOLT FLANGE 8X 32 | 958010803200 |
|
