| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | CABLE COMP. A, THROTTLE | 17910K45N41 |
|
| 2 | CABLE COMP. B, THROTTLE | 17920K45N41 |
|
| 3 | CABLE COMP., CLUTCH | 22870K45N40 |
|
| 4 | SWITCH ASSY., START | 35130K45NL1 |
|
| 5 | COVER, CLUTCH SWITCH | 35152KRY970 |
|
| 6 | SWITCH ASSY., WINKER . | 35200K45NL1 |
|
| 6 | SWITCH ASSY., WINKER . | 35200K45NL2 |
|
| 6 | SWITCH ASSY., WINKER . | 35200K45N42 |
|
| 7 | SWITCH COMP., FR. LEVER (TOYO DENSO) | 35330413003 |
|
| 8 | HOLDER, MASTER CYLINDER | 45517166006 |
|
| 9 | GRIP COMP., THROTTLE | 53140K45N00 |
|
| 10 | GRIP, L. HANDLE | 53166KYJ900 |
|
| 11 | BRACKET, HANDLE LEVER | 53172KT7751 |
|
| 12 | PLUG, HANDLE LEVER BRACKET | 53174KYJ710 |
|
| 13 | LEVER COMP., L. HANDLE | 53178K45N00 |
|
| 14 | BOOT, HANDLE LEVER | 53180425010 |
|
| 15 | BOLT, CLUTCH WIRE ADJUSTING | 53192349690 |
|
| 16 | BOLT, L. STEERING HANDLE LEVER PIVOT | 90113438000 |
|
| 17 | NUT, FIXING | 90321MR8000 |
|
| 18 | BAND, WIRE, 165MM(BLACK) | 90651KV6003 |
|
| 19 | BAND, WIRE(BLACK) | 90652KT1771 |
|
| 20 | SCREW-WASHER, 5X20 | 938920502007 |
|
| 21 | NUT, HEX., 8MM | 94002080000S |
|
| 22 | NUT, HEX., 8MM | 9403008000 |
|
| 23 | NUT, FLANGE, 6MM | 9405006000 |
|
| 24 | BOLT, FLANGE, 6X22 | 960010602207 |
|
