| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | COLLAR, AIR CLEANER MOUNTING | 17232KYJ900 |
|
| 2 | COLLAR, 5MM | 18295GW0920 |
|
| 3 | RUBBER MOUNT | 19639GBC000 |
|
| 4 | RUBBER B, MOUNTING | 61106KW6840 |
|
| 5 | COWL,R SIDE | 64321K45NL0 |
|
| 6 | COWL,L SIDE | 64421K45NL0 |
|
| 7 | COWL, SET , R. RR TYPE 1 | 83110K45A20ZB |
|
| 7 | COWL, SET , R. RR TYPE 1 | 83110K45A40ZA |
|
| 7 | SET ILLUS,R REAR COWL TYPE 1 | 83110K45NZ0ZA |
|
| 7 | COWL,R REAR (VA RD) | 83111K45NL0ZA |
|
| 7 | COWL,R REAR (WN RD) | 83111K45NL0ZB |
|
| 7 | COWL,R REAR (AN GY MT) | 83111K45NL0ZC |
|
| 7 | COWL,R REAR (RO WH) | 83111K45NL0ZD |
|
| 7 | COWL,R REAR (BLK) | 83111K45NL0ZE |
|
| 7 | SET ILLUS,R REAR COWL, TYPE 1 | 83110K45A60ZA |
|
| 7 | SET ILLUS,R REAR COWL, TYPE 1 | 83110K45A50ZA |
|
| 8 | SET ILLUS,L REAR COWL TYPE 1 | 83120K45A40ZA |
|
| 8 | SET ILLUS,L REAR COWL TYPE 1 | 83120K45A20ZB |
|
| 8 | SET ILLUS,L REAR COWL TYPE 1 | 83120K45NZ0ZA |
|
| 8 | COWL,L REAR (WN RD) | 83121K45NL0ZB |
|
| 8 | COWL,L REAR (AN GY MT) | 83121K45NL0ZC |
|
| 8 | COWL,RR CENTER (BLK) | 83121K45NL0ZE |
|
| 8 | COWL,L REAR (VA RD) | 83121K45NL0ZA |
|
| 8 | SET ILLUS,L REAR COWL, TYPE 1 | 83120K45A60ZA |
|
| 8 | SET ILLUS,L REAR COWL, TYPE 1 | 83120K45A50ZA |
|
| 9 | SET ILLUS,RR CENTER COWL TYPE 2 | 83130K45NL0ZC | - |
| 9 | SET ILLUS,RR CENTER COWL TYPE 3 | 83130K45NL0ZB | - |
| 9 | SET ILLUS,RR CENTER COWL TYPE 4 | 83130K45NL0ZA | - |
| 9 | COWL,RR CENTER (AN GY MT) | 83131K45NL0ZC |
|
| 9 | COWL,RR CENTER (RO WH) | 83131K45NL0ZD |
|
| 9 | COWL,RR CENTER (BLK) | 83131K45NL0ZE |
|
| 9 | Cowl Rr Center (MT GN BL) | 83131K45NL0MGB |
|
| 9 | SET ILLUS,RR CENTER COWL, TYPE 3 | 83130K45A50ZA |
|
| 9 | Set Illust Rear Center Cowl TYPE 2 | 83130K45A50ZB |
|
| 9 | Set Illust RR Center Cowl Type 1 | 83130K45A50ZC |
|
| 10 | COVER,SEAT LOCK (WN RD) | 83141K45NL0ZC |
|
| 10 | COVER,SEAT LOCK (VA RD) | 83141K45NL0ZB |
|
| 10 | COVER,SEAT LOCK (BLK) | 83141K45NL0ZE |
|
| 10 | COVER,SEAT LOCK (MT GN BL) | 83141K45NL0ZD |
|
| 10 | COVER,SEAT LOCK (NI OR) | 83141K45NL0ZA |
|
| 10 | Cover Seat Lock (RO WH) | 83141K45NL0ZN |
|
| 11 | RUBBER COVER | 83545KCJ690 |
|
| 12 | GROMMET A/C | 83551GE2000 |
|
| 13 | NUT COWL SET M5X0.8 | 90111KW3003 |
|
| 14 | RIVET PUSH 6MM | 90116K0AE11 |
|
| 15 | SCREW,PAN 6X10 | 90132KPPT00 |
|
| 16 | SCREW, PAN, 5X14 | 90134K45N40 |
|
| 17 | WASHER, 6MM | 90485MB2000 |
|
| 18 | PLUG, CONE TYPE | 90899422610 |
|
| 19 | SCREW-WASH,5X18 | 938940501807 |
|
| 20 | BOLT FLANGE SH 6X18 | 960010601800 |
|
