| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | FORK ASSY,R FRONT (STD) | 51400K45307 |
|
| 1 | FORK ASSY,R FRONT (ABS) | 51400K45308 |
|
| 2 | SPRING,FR FORK | 51401K45NL1 |
|
| 3 | COLLAR COMP R,SPG | 51402K45NL1 |
|
| 4 | TUBE,OUTER | 51410K45305 |
|
| 5 | RING, BACK UP | 51412461003 |
|
| 6 | SPRING R,REBOUND | 51412K45NL1 |
|
| 7 | BUSH, GUIDE | 51414K31901 |
|
| 8 | BUSH, SLIDER | 51415KSEA71 |
|
| 9 | SEAT, STOPPER | 51419K45NL1 |
|
| 10 | PIPE COMP,R SLIDE (STD) | 51425K45305 |
|
| 10 | PIPE COMP,R SLIDE (ABS) | 51425K45306 |
|
| 11 | ROD COMP,PISTON | 51426K45NL1 |
|
| 12 | CIRCLIP, INTERNAL, 50MM | 51447461003 |
|
| 13 | RING,OIL SEAT STOP | 51447KR6003 |
|
| 14 | BOLT COMP,FR FORK | 51450K45NL1 |
|
| 15 | NUT,HEX | 51451MKYD51 |
|
| 16 | CASE COMP,ROD GUIDE | 51455K45NL1 |
|
| 17 | RING STOPPER | 51455K64N00 |
|
| 18 | RING,STOPPER | 51456K45NL1 |
|
| 19 | SEAL SET,FR FORK | 51490KWL003 |
|
| 20 | FORK ASSY, L FRONT | 51500K45307 |
|
| 21 | COLLAR COMP B,SPG | 51502K45NL1 |
|
| 22 | SPRING L,REBOUND | 51512K45NL1 |
|
| 23 | SEAT,L STOPPER | 51519K45NL1 |
|
| 24 | PIPE COMP,L SLIDE | 51525K45305 |
|
| 25 | ROD COMP | 51526K45NL1 |
|
| 26 | BOLT,FLANGE,8X45 | 90109MR7000 |
|
| 27 | SEAL DUST | 91254KAZ003 |
|
| 28 | O-RING, 37.2X2.4(SHOWA) | 91356MW0003 |
|
