| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | COVER,CENTER (BLACK) | 80151K1AN00ZA |
|
| 2 | COVER,R BODY (MT GN BL) | 83500K1AN00MGB |
|
| 2 | COVER,R BODY (MT CR SL) | 83500K1AN00MCS |
|
| 2 | COVER,R BODY (BLK) | 83500K1AN00FMB |
|
| 2 | COVER,R BODY (RO WH) | 83500K1AN00RSW |
|
| 2 | SET ILLUST,R BODY COVER TYPE 3 | 83505K1AN00ZA |
|
| 2 | SET ILLUST,R BODY COVER TYPE 2 | 83505K1AN00ZB |
|
| 2 | SET ILLUST,R BODY COVER TYPE 1 | 83505K1AN00ZC | - |
| 2 | COVER,R BODY (MT BU SL) | 83500K1AN00MBS |
|
| 2 | COVER,R BODY (MT SA GR) | 83500K1AN00MSG |
|
| 2 | Cover R Body (MA JB MT) | 83500K1AN00MJB |
|
| 2 | Cover R Body (MA BL MT) | 83500K1AN00MIB |
|
| 3 | COVER,R BODY SIDE (BLACK) | 83520K1AN00ZA |
|
| 4 | COVER,L BODY (MT GN BL) | 83600K1AN00MGB |
|
| 4 | COVER,L BODY (MT CR SL) | 83600K1AN00MCS |
|
| 4 | COVER,L BODY (BLK) | 83600K1AN00FMB |
|
| 4 | COVER,L BODY (RO WH) | 83600K1AN00RSW |
|
| 4 | Cover L Body (MA JB MT) | 83600K1AN00MJB |
|
| 4 | SET ILLUST,L BODY COVER TYPE 3 | 83605K1AN00ZA |
|
| 4 | SET ILLUST,L BODY COVER TYPE 2 | 83605K1AN00ZB |
|
| 4 | SET ILLUST,L BODY COVER TYPE 1 | 83605K1AN00ZC |
|
| 4 | COVER,L BODY (MT BU SL) | 83600K1AN00MBS |
|
| 4 | COVER,L BODY (MT SA GR) | 83600K1AN00MSG |
|
| 5 | COVER,L BODY SIDE (BLACK) | 83620K1AN00ZA |
|
| 6 | COVER,RR CENTER MBNH-1 | 83700K1AN00ZA |
|
| 7 | NUT SPRING 4MM | 90302KWWA00 |
|
| 8 | NUT CLIP 5MM. | 90677KANT00 |
|
| 9 | SCREW TAPPING 4X12 | 9390334320 |
|
| 10 | SCREW TAPPING 4X12 | 9390334380 |
|
