| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | Cover Front (MA JB MT) | 64301K1AN00MJB |
|
| 1 | COVER,FR (MT GN BL) | 64301K1AN00MGB |
|
| 1 | COVER,FR (MT CR SL) | 64301K1AN00MCS |
|
| 1 | COVER,FR (HU SL ME) | 64301K1AN00HSM |
|
| 1 | COVER,FR (BLK) | 64301K1AN00FMB |
|
| 1 | COVER,FR (RO WH) | 64301K1AN00RSW |
|
| 1 | COVER,FR (VA RD) | 64301K1AN00VRD |
|
| 1 | COVER,FR (AR BL ME) | 64301K1AN00ARB |
|
| 1 | SET ILLUST,FR COVER, TYPE 4 | 64300K1AN00ZE |
|
| 1 | SET ILLUST,FR COVER, TYPE 3 | 64300K1AN00ZF | - |
| 1 | SET ILLUST,FR COVER, TYPE 2 | 64300K1AN00ZG |
|
| 1 | SET ILLUST,FR COVER, TYPE 1 | 64300K1AN00ZH | - |
| 2 | COVER,FR TOP (BLACK) | 64302K1AN00ZA |
|
| 3 | COVER,FR LOWER (BLACK) | 64308K1AN00ZA |
|
| 4 | COVER,UNDER (BLACK) | 64340K1AN00ZA |
|
| 5 | COVER,INNER UPPER (BLACK) | 81131K1AN00ZA |
|
| 5 | COVER,INNER UPPER | 81131K1AN10ZA |
|
| 6 | HOOK LUGGAGE | 81132GAH000YV |
|
| 7 | COVER,INNER LOWER (BLACK) | 81141K1AN00ZA |
|
| 8 | BOLT SPECIAL 6MM | 90107KVB900 |
|
| 9 | RIVET PUSH 6MM | 90116K0AE11 |
|
| 10 | NUT SPRING 4MM | 90302KWWA00 |
|
| 11 | CLIP SNAP FIT(PO) | 90666K59A11 |
|
| 12 | SCREW PAN 5X11.5 | 91509GE2760 |
|
| 13 | SCREW TAPPING 4X12 | 9390334320 |
|
| 14 | SCREW TAPPING 4X12 | 9390334380 |
|
| 15 | BOLT FLANGE 6X12 | 957010601207 |
|
| 16 | BOLT FLANGE 6X12 | 957010601208 |
|
