| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | CABLE COMP. A, THROTTLE (HX) | 17910K1AN01 |
|
| 1 | CABLE COMP A,THROT | 17910K1AN02 |
|
| 2 | CABLE COMP. B, THROTTLE (HX) | 17920K1AN01 |
|
| 2 | CABLE COMP B,THROT | 17920K1AN02 |
|
| 3 | SWITCH UNIT, STARTER (T0) | 35160K20T21 |
|
| 3 | SWITCH UNIT, STARTER | 35160K27V01 |
|
| 4 | SWITCH UNIT, DIMMER (T0) | 35170K93N01 |
|
| 4 | SW UNIT,DIMMER | 35170K1AN11 |
|
| 5 | SWITCH UNIT, HORN (T0) | 35180K20T21 |
|
| 5 | SWITCH UNIT, HORN | 35180K47N01 |
|
| 6 | SWITCH UNIT, IDLE (AS) | 35190K1AN11 |
|
| 7 | SWITCH UNIT, WINKER (T0) | 35200K03N31 |
|
| 7 | SWITCH UNIT, WINKER | 35200K47N01 |
|
| 8 | SWITCH ASSY., FR. STOP | 35340KPH901 |
|
| 9 | CABLE COMP., FR BRAKE CONNECTING | 43440K1AN01 |
|
| 9 | CABLE COMP,FR BRK CONN. | 43440K1AN11 |
|
| 10 | CABLE COMP.,RR. BRAKE | 43450K1AN01 |
|
| 10 | CABLE COMP,RR BRK | 43450K1AN11 |
|
| 11 | CLAMPER A, RR. BRAKE CABLE | 43455K0JN00 |
|
| 12 | CLAMPER B, RR BRAKE CABLE | 43456K1AN00 |
|
| 13 | HOLDER, MASTER CYLINDER | 45517K44V81 |
|
| 14 | GRIP, L. HANDLE | 53166KWB600 |
|
| 15 | GRIP, L. HANDLE | 53166KWB600 |
|
| 15 | GRIP, L. HANDLE | 53166K2SN00 |
|
| 16 | HOUSING , UPPER THROTTLE | 53167K66V00 |
|
| 17 | HOUSING, UNDER THROTTLE | 53168K66V00 |
|
| 18 | BRACKET, L. BRAKE LEVER | 53172K1AN00 |
|
| 19 | COVER, L. BRAKE LEVER BRAKCET | 53173K0JN00 |
|
| 20 | LEVER, L. STEERING HANDLE | 53178K1AN00 |
|
| 21 | EQUALIZER COMP., | 53184K59A70 |
|
| 22 | LEVER COMP., BRAKE LOCK | 53185K1AN00 |
|
| 23 | PIN, BRAKE LOCK LEVER | 53186K81N30 |
|
| 24 | SPRING , BRAKE LOCK ARM RETURN | 53188K81N30 |
|
| 25 | SCREW , PAN, 5X8 | 90104K81N30 |
|
| 26 | SCREW, HANDLE LEVER PIVOT | 90115K1AN00 |
|
| 27 | SCREW, HANDLE LEVER PIVOT | 90115KWN900 |
|
| 28 | NUT,U,5MM | 90302KVBT01 |
|
| 29 | SCREW, PAN, 5 X20 | 93500050200A |
|
| 30 | E-RING, 3MM | 9454003010 |
|
| 31 | BOLT, FLANGE, 6X12 | 960010601200 |
|
| 32 | BOLT, FLANGE, 6X22 | 960010602200 |
|
