| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | SWITCH FR STOP ASSY | 35340MGSD31 |
|
| 2 | HOSE COMP. A, FR. BRAKE | 45125K0FD11 | - |
| 2 | HOSE COMP A FR BR | 45125K0FA11 | - |
| 3 | HOSE COMP. B, FR. BRAKE | 45128K0FD11 | - |
| 3 | HOSE COMP B FR BR | 45128K0FA11 | - |
| 4 | CLAMPER A, FR. BRAKE HOSE | 45156K0FD10 | - |
| 5 | STAY B, FR. BRAKE HOSE | 45157K0FD10 | - |
| 6 | STAY C, FR. BRAKE HOSE | 45158K0FD10 | - |
| 7 | BOOT COMP | 45504410003 |
|
| 8 | CYLINDER SUB ASSY FR BRAKE | 45510K0FT01 | - |
| 9 | PROTECTOR | 45512MA6006 |
|
| 10 | CAP,MASTER CYLINDER | 45513GW0911 |
|
| 11 | HOLDER MASTER CYL | 45517166006 |
|
| 12 | DIAPHRAGM | 45520GW0911 |
|
| 13 | PLATE,DIAPHRAGM | 45521GW0911 |
|
| 14 | CYLINDER SET,MAS | 45530471831 |
|
| 15 | LEVER R STEERING HANDLE | 53175K26901 |
|
| 16 | BOLT FLANGE SH 6X10 | 90013GHB600 | - |
| 17 | BOLT FLANGE SH 6X12 | 90013GHB610 | - |
| 18 | BOLT FLANGE SH 6X | 90013GHB660 | - |
| 19 | BOLT HANDLE LEVER | 90114KGH900 |
|
| 20 | BOLT OIL 10X22 | 90145MS9612 | - |
| 20 | BOLT OIL, 10X22 (NISSIN) | 90145KPHB30 |
|
| 21 | NUT, CAP, 6MM | 90304GFM970 | - |
| 22 | WASHER OIL BOLT | 90545300000 |
|
| 23 | CIRCLIP | 90651MA5671 |
|
| 24 | SCREW FLAT, 4X12 | 93600040121G |
|
| 25 | SCREW WASHER 4X12 | 938930401217 |
|
| 26 | NUT,FLANGE 6MM | 9405006000 |
|
| 27 | BOLT,FLANGE 6X18 | 960010601807 |
|
