| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | COVER R CRANK CASE | 11330KPH880 |
|
| 2 | PROTECTOR R COVER | 11370KPH880 |
|
| 3 | GASKET R CRANKCASE COVER | 11394KPH900 |
|
| 4 | GAUGE OIL LEVEL | 15651KPH880 |
|
| 5 | LEVER COMP.,CLUTCH | 22810KPH900 |
|
| 6 | CAM PLATE COMP CLUTCH | 22820KPH700 |
|
| 7 | SPRING CAM PLATE SIDE | 22825046001 |
|
| 8 | PLATE COMP CLUTCH LIFTER | 22830KPH901 |
|
| 9 | BOLT CLUTCH ADJUST | 22846KPH901 |
|
| 10 | PLATE COMP, BRAKE | 22850KPH900 |
|
| 11 | SPG, BRAKE | 22853KPH900 |
|
| 12 | RETAINER COMP BALL | 22860HB3001 |
|
| 13 | BOLT FLANGE NSHF 6X12 | 90004GHB610 |
|
| 14 | WASHER,THRUST 8MM | 90443844000 |
|
| 15 | WASHER 8MM | 90485040001 |
|
| 16 | CIRCLIP 7MM | 90605166720 |
|
| 17 | PIN DOWEL 8X12 | 90702KFM900 |
|
| 18 | BRG,BALL RADIAL 6001U | 91007KPH901 |
|
| 19 | OIL SEAL, 16X28X7 | 91204MC7003 |
|
| 20 | ORING 8MM | 91303001000 |
|
| 21 | O-RING, 18X3 | 91307035000 |
|
| 22 | NUT HEX 8MM | 9403008000 |
|
| 23 | BOLT FLANGE 6X40 | 960010604000 |
|
