| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | SWITCH UNIT LIGHTING | 35150KPH880 |
|
| 2 | SWITCH UNIT START | 35160KPH881 |
|
| 3 | SWITCH UNIT DIMMER | 35170KPH901 |
|
| 4 | SWITCH UNIT HORN | 35180KPH881 |
|
| 5 | SWITCH UNIT WINKER | 35200KPH901 |
|
| 6 | RUBBER MAIN STEP MOUNT | 50613KFL850 |
|
| 7 | PIPE COMP STRG HANDLE | 53100KPH880 | - |
| 8 | WEIGHT B STRG HDL | 53104KPH720 | - |
| 9 | WEIGHT A STRG HDL(Y) | 53105KPH720 |
|
| 10 | RUBBER A HANDLE WEIGHT | 53106KR3000 |
|
| 11 | RING HDL WHT SNAP | 53108KR3770 |
|
| 12 | COLLAR HDL MOUNTING | 53109KPH900 |
|
| 13 | POST COMP HDL | 53120KPH880 | - |
| 13 | 53120KPH890 | 53120KPH890 | - |
| 14 | 53205KPH880FMB | 53205KPH880FMB | - |
| 14 | 53205KPH880FMH | 53205KPH880FMH | - |
| 14 | 53205KPH890FMB | 53205KPH890FMB |
|
| 14 | 53205KPH890FMH | 53205KPH890FMH |
|
| 14 | 53205KPH730FMK | 53205KPH890FMK | - |
| 15 | COVER HDL RR(BLK) | 53206KPH880FMB | - |
| 15 | COVER HDL RR(SLV) | 53206KPH880FMH | - |
| 15 | 53206KPH890FMB | 53206KPH890FMB | - |
| 15 | 53206KPH890FMH | 53206KPH890FMH | - |
| 15 | 53206KPH890FMK | 53206KPH890FMK | - |
| 16 | NUT CLIP 4MM | 64521MN5000 |
|
| 17 | EMBLEM, WING MARK | 86150KPG901 |
|
| 18 | BOLT FLANGE 10X50 | 90106GN5900 |
|
| 19 | SCREW OVAL 6X70 | 90191KPH880 | - |
| 20 | NUT U10MM | 90304KGH901 |
|
| 21 | COLLAR A HNDL SET | 90501GBY910 | - |
| 22 | 90505GBY910 | 90505GBY910 | - |
| 23 | SCREW PAN 5X11.5 | 91509GE2760 |
|
| 24 | BOLT HEX 8X25 | 92101080250H | - |
| 25 | SCREW WASHER 4X16 | 938910401608 |
|
| 26 | SCREW WASHER 4X20 | 938910402007 | - |
| 27 | SCREW TAPPING 4X12 | 9390324310 |
|
