| 1 |
KIT,FUEL FILTER |
06160KPPT00 |
-
|
| 2 |
CLIP OIL DRAIN TUBE |
15771KV6000 |
|
| 3 |
UNIT ASSY,FUEL PUMP |
16700KPPT01 |
-
|
| 4 |
DAMPER,CONNECTOR |
16718GFZ000 |
-
|
| 5 |
PLATE,SETTING |
17507KPPT00 |
-
|
| 6 |
PACKING,FUEL PUMP |
17515GBJM30 |
-
|
| 7 |
TANK ST, FUEL ASTRD BLK MET |
17520KPPT00ZB |
-
|
| 7 |
TANK ST, FUEL ROSS WHITE |
17520KPPT00ZC |
-
|
| 7 |
TANK ST, FUEL MILLNM RED |
17520KPPT00ZD |
-
|
| 8 |
STAY,FUEL TANK SUP |
17521KPPT00 |
-
|
| 9 |
STAY,TANK LID |
17522KPPT00 |
|
| 10 |
CLAMPER,F/FEED |
17568KTYD30 |
-
|
| 11 |
HOSE COMP.FUEL FEED |
17570KPPT00 |
-
|
| 12 |
CUSH,FUEL TANK RR PIVOT |
17572KPPT00 |
-
|
| 13 |
TUBE,DRAIN |
17576KPPT00 |
-
|
| 14 |
RETAINER |
17577KSSB31 |
|
| 15 |
CUSH.FUEL TANK RR |
17613KPPT00 |
|
| 16 |
COLLAR,FUEL TANK |
17614KPPT00 |
-
|
| 17 |
CAP COMP,FUEL FILLER |
17620KPP931 |
-
|
| 18 |
RETAINER |
17711MGE003 |
-
|
| 19 |
FUEL UNIT |
37800KPPT01 |
-
|
| 20 |
GUIDE,BREATHER TUBE |
50187KPPT00 |
-
|
| 21 |
CVR,FUEL TNK ASTRD BLK MT |
64450KPPT00ZA |
-
|
| 21 |
COVER, FUEL TANK ROSS WHITE |
64450KPPT00ZB |
-
|
| 21 |
COVER, FUEL TANK MILLNM RED |
64450KPPT00ZC |
-
|
| 22 |
CASE GROMMET |
83551300000 |
|
| 23 |
BOLT,TANK HINGE |
90135KPPT00 |
-
|
| 24 |
CLIP BAND HARN (U DIA 15) |
91540KPH902 |
|
| 25 |
NUT,FLANGE 6MM |
9405006000 |
|
| 26 |
BOLT WASH |
934010601400 |
|
| 27 |
BOLT FLANGE 6X16 |
957010601600 |
|
| 28 |
BOLT FLANGE 8X40 |
957010804000 |
|
| 29 |
RUBBER,FUEL TANK |
17525KPPT00 |
-
|
| 30 |
RUBBER SPONGE,TAN |
64455KPPT00 |
-
|
| 31 |
CVR ASSY,TANK/R263 |
64700KPPT00ZA |
-
|
| 31 |
CVR ASSY,TANK/NH196 |
64700KPPT00ZB |
-
|
| 31 |
CVR ASSY,TANK/NHA35M |
64700KPPT00ZC |
-
|
| 32 |
TUBE FUEL TANK BR SHROUD |
17575KPP600 |
-
|
| 33 |
CLIP HARN |
90659680013 |
-
|
