| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | RUBBER B, HEAD SIDE COVER | 12372KGB610 | - |
| 2 | GUARD, NUMBER PLATE | 61316KCJ661 |
|
| 3 | COVER A, FR. UPPER | 64131MJWJ80 | - |
| 4 | COVER B, FR. UPPER | 64141MJWJ80ZA | - |
| 5 | COVER, FR. UNDER | 64151MJWJ80 | - |
| 6 | RUBBER SCREEN SETTING | 64216GJ2730 |
|
| 7 | 64221MJWJ80 | 64221MJWJ80 | - |
| 7 | STAY COMP., FR. UPPER COWL | 64221MJW960 | - |
| 8 | STAY, R. SCREEN | 64224MJWJ80 | - |
| 9 | STAY COMP., NUMBER PLATE(FR.) | 64231MJW960 | - |
| 10 | STAY, L. SCREEN | 64234MJWJ80 | - |
| 11 | PANEL, METER | 64260MGZJ80 | - |
| 12 | LID, POSITION BULB | 64261MGZJ80 | - |
| 13 | PANEL, R. INNER | 64270MGZJ81 | - |
| 14 | PANEL, L. INNER | 64280MGZJ81 | - |
| 15 | WINDSCREEN | 67101MJWJ80 | - |
| 16 | SCREW, PAN, 6X10 | 90106GBB710 | - |
| 17 | NUT COWL SET M5X0.8 | 90111KW3003 |
|
| 18 | RIVET, PUSH | 90116MCSG00 | - |
| 19 | SCREW, PAN, 5X20 | 90117MGZJ80 | - |
| 20 | SCREW,PAN 6X14 | 90133KPPT00 | - |
| 21 | SCREW,PAN 5X14 | 90134KPPT00 |
|
| 22 | NUT CAP,8MM | 90443KTM970 |
|
| 23 | WASHER, THRUST 5MM | 90504964000 |
|
| 24 | WASHER, NYLON, 9MM | 90507ZV1000 |
|
| 25 | NUT CLIP 5MM. | 90677KANT00 |
|
| 26 | SCREW TAPPING 4X12 | 9390324380 |
|
| 27 | NUT FLANGE 6MM | 9405006070 |
|
| 28 | BOLT FLANGE 8X 32 | 958010803200 |
|
| 29 | BOLT FLANGE 6X12 | 960010601207 |
|
