| 1 |
RING SET, PISTON(STD.) |
13011MEE305 |
-
|
| 1 |
RING SET, PISTON(0.25) |
13021MEE305 |
-
|
| 2 |
PISTON(STD) |
13101MGZD00 |
-
|
| 2 |
PISTON(0.25) |
13102MGZ305 |
-
|
| 3 |
PIN, PISTON |
13111MFGD00 |
-
|
| 4 |
CLIP, PISTON PIN, 16MM |
13115MGZJ00 |
-
|
| 5 |
ROD ASSY., CONNECTING |
13210MGZD00 |
-
|
| 6 |
BOLT, CONNECTING ROD |
13213ML7020 |
-
|
| 7 |
BEARING A, CONNECTING ROD |
13214MGZJ01 |
-
|
| 7 |
BEARING B, CONNECTING ROD |
13215MGZJ01 |
-
|
| 7 |
BEARING C, CONNECTING ROD |
13216MGZJ01 |
-
|
| 7 |
BEARING D, CONNECTING ROD |
13217MGZJ01 |
-
|
| 7 |
BEARING E, CONNECTING ROD |
13218MGZJ01 |
-
|
| 8 |
NUT, CONNECTING ROD |
13215ML7000 |
-
|
| 9 |
CRANKSHAFT COMP. |
13300MGZD01 |
-
|
| 10 |
BEARING A, CRANKSHAFT(BLACK) |
13313MW0003 |
-
|
| 10 |
BEARING B, CRANKSHAFT(BROWN) |
13314MW0003 |
-
|
| 10 |
BEARING C, CRANKSHAFT(GREEN) |
13315MW0003 |
-
|
| 10 |
BEARING D, CRANKSHAFT(YELLOW) |
13316MW0003 |
-
|
| 10 |
BEARING E, CRANKSHAFT(PINK) |
13317MW0003 |
-
|
| 11 |
SHAFT COMP., BALANCER(40T) |
13420MGZD01 |
-
|
| 12 |
SPROCKET, TIMING(17T) |
14311MGZJ00 |
-
|
| 13 |
GEAR, PRIMARY DRIVE(34T) |
23113MGZJ00 |
-
|
| 14 |
SUB GEAR, PRIMARY(34T) |
23114MGZJ00 |
-
|
| 15 |
SPRING, PRIMARY DRIVE GEAR |
23115MV1300 |
-
|
| 16 |
BOLT, SPECIAL, 10X25 |
90013MGZJ00 |
-
|
| 17 |
WASHER, 10.5X40 |
90405MGZJ00 |
-
|
| 18 |
KEY,WOODRUFF,25X18 |
90742KYJ900 |
|
| 19 |
BEARING, SPECIAL RADIAL BALL |
91001MGZJ00 |
-
|
