| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | Collar Air Cleaner Mounting | 17232KYJ900 |
|
| 2 | Step Floor (BLK) | 64310K0JN00ZB |
|
| 2 | StepFloor (CA BR) | 64310K0JN00ZA |
|
| 2 | Step Floor (BLK) | 64310K0JN00ZC |
|
| 4 | Cover R Under Side (VA RD) | 64421K0JN00ZB |
|
| 4 | Cover R Under Side (PL BL ME) | 64421K0JN00ZG |
|
| 4 | Cover R Under Side (RO WH) | 64421K0JN00ZD |
|
| 4 | Cover R Under Side (BLK) | 64421K0JN00ZE |
|
| 4 | Cover R Under Side (HU SL ME) | 64421K0JN00ZF |
|
| 4 | Cover R Under Side (MO BR ME) | 64421K0JN00ZA |
|
| 4 | Cover R Under Side (AR BL ME) | 64421K0JN00ZH |
|
| 4 | Cover R Under Side (MT SA GR) | 64421K0JN00MSG |
|
| 4 | Cover R Under Side (MT GN BL) | 64421K0JN00ZC |
|
| 4 | Cover R Under Side (MA BL MT) | 64421K0JN00ZM |
|
| 6 | Cover L Under Side Ma Bl Mt | 64431K0JN00ZM |
|
| 6 | Cover L Under Side (VA RD) | 64431K0JN00ZB |
|
| 6 | Cover L Under Side (PL BL ME) | 64431K0JN00ZG |
|
| 6 | Cover L Under Side (RO WH) | 64431K0JN00ZD |
|
| 6 | Cover L Under Side (BLK) | 64431K0JN00ZE |
|
| 6 | Cover L Under Side (HU SL ME) | 64431K0JN00ZF |
|
| 6 | Cover L Under Side (MO BR ME) | 64431K0JN00ZA |
|
| 6 | Cover L Under Side (AR BL ME) | 64431K0JN00ZH |
|
| 6 | Cover L Under Side (MT GN BL) | 64431K0JN00ZC |
|
| 6 | Cover L Under Side (MT SA GR) | 64431K0JN00MSG |
|
| 7 | Lid Battery (BLK) | 64460K0JN00ZB |
|
| 7 | Lid Battery (CA BR) | 64460K0JN00ZA |
|
| 8 | Rubber Cover | 83545KCJ690 |
|
| 9 | Bolt Special 6MM | 90101K15900 |
|
| 10 | Rivet Push 6MM | 90116K0AE11 |
|
| 11 | Nut Spring 4MM | 90302KWWA00 |
|
| 12 | Screw Tapping 4X12 | 9390334380 |
|
| 12 | Screw Tapping 4X12 | 9390334310 |
|
| 13 | Bolt Flange 6X20 | 957010602007 |
|
| 13 | Bolt Flange 6X20 | 957010602000 |
|
