| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | AXLE RR WHEEL | 42301KFM900 |
|
| 2 | COLLAR,RR AXLE DIST | 42620KTR700 |
|
| 3 | VALVE,RIM (INOUE) | 42753GM9743 |
|
| 3 | VALVE,RIM(TRITON) | 42753KWF901 |
|
| 4 | COLLAR FR WHEEL SIDE | 44311KVB910 |
|
| 5 | COLLAR, FR. WHEEL SIDE | 44312KZR600 |
|
| 6 | WHEEL SUB ASSY FR (GREY) | 44650K93N00ZA |
|
| 7 | TIRE FR TL (100/90-12) | 44711K93N02 |
|
| 7 | TIRE FR(IRC) | 44711K93N03 | - |
| 8 | DISK,FR BRAKE | 45351K0JN01 |
|
| 8 | DISK,FR BRAKE | 45351K2SN01 |
|
| 8 | DISK,FR BRAKE | 45351K93N01 |
|
| 8 | DISK FR BRAKE | 45351KVBS02 |
|
| 9 | BOLT BRK DISK 8X24 | 90105KGH900 |
|
| 10 | NUT,U,12MM | 90306KGH901 |
|
| 11 | BRG BALL RADIAL 6201U L | 91052K03N41 |
|
| 11 | BRG,BALL RADIAL 6201U L | 91052K24903 |
|
| 11 | BRG,BALL RADIAL 6201U L | 91052K24902 |
|
| 11 | BRG,BALL RADIAL 6201U L | 91052K24903 |
|
| 11 | BEARING RADIAL BALL(6201U L) | 91052K24904 |
|
| 12 | DUST SEAL 21 X 37 X 7 | 91251KPH901 |
|
| 12 | DUST SEAL 21 X 37 X 7 | 91251K35V01 |
|
| 13 | DUST SEAL, 21X32X5 | 91251KZR601 |
|
