| # | Nama Part | Nomor Part | Gambar |
|---|---|---|---|
| 1 | RADIATOR COMP | 19010K1BT01 | - |
| 2 | SET NUT | 19014KEA003 |
|
| 3 | SHROUD COMP | 19015K1BT01 | - |
| 4 | TUBE A RESERVE TA | 19016K1BT00 | - |
| 5 | SCREW,PAN,4X8.5 | 19016KEA003 |
|
| 6 | FAN COMP., COOLING(T.RAD) | 19020MGSD31 | - |
| 7 | MOTOR ASSY FAN | 19030K1BT01 | - |
| 8 | FILLER NECK | 19035K04931 | - |
| 9 | CAP COMP.RAD | 19037KVB902 |
|
| 9 | CAP COMP., RADIATOR | 19037MCAG61 | - |
| 10 | LABEL,RAD CAP | 19046KVB902 |
|
| 10 | LABEL, RADIATOR CAP | 19046MCAG61 | - |
| 11 | RUB RADIATOR MTG. | 19051MB2000 | - |
| 12 | TANK RESERVE | 19101K1BT00 | - |
| 13 | CAP, RESERVE TANK | 19104MB0700 |
|
| 14 | SHROUD RADIATOR | 19122K1BT00 | - |
| 15 | HOSE FILLER | 19126K1BT00 | - |
| 16 | HOSE A WATER | 19501K1BT00 | - |
| 17 | HOSE B WATER | 19502K1BT00 | - |
| 18 | HOSE C WATER | 19503K1BT00 | - |
| 19 | HOSE D WATER | 19504K1BT00 | - |
| 20 | PIPE A WATER | 19505K1BT00 | - |
| 21 | PIPE B WATER | 19506K1BT00 | - |
| 22 | CLAMP WATER B | 19507KA3830 | - |
| 23 | CLAMP TUBE D 19 | 19509KPH900 |
|
| 24 | CLAMPER WATER HOS | 19530K1BT00 | - |
| 25 | CLAMPER B WATER H | 19532K1BT00 | - |
| 26 | 61104428010 | 61104428730 | - |
| 27 | COLLAR FR FENDER | 61112K97T00 |
|
| 28 | RUBBER,HEADLIGHT | 61304415000 |
|
| 29 | BOLT FLANGE 6MM | 90111162000 |
|
| 30 | BOLT,WASH 6X16 | 90120KCR003 |
|
| 31 | NUT, FLANGE, 3MM | 90315MFL003 |
|
| 32 | WASHER SEAL 6MM | 90441706000 | - |
| 33 | CLIP B10,TUBE | 9500202100 |
|
| 34 | CLIP B12,TUBE | 9500202120 |
|
| 35 | CLIP,TUBE 5.0 MM | 9500250000 |
|
| 36 | TUBE 5X220 | 950055022030 | - |
| 37 | BOLT FLANGE 6X8 | 957010600808 | - |
| 38 | BOLT FLANGE 6X12 | 957010601200 |
|
| 39 | BOLT FLANGE 6X12 | 957010601208 |
|
| 40 | BOLT FLANGE 6X14 | 957010601400 |
|
| 41 | BOLT,FLANGE 6X16 | 957010601608 |
|
| 42 | BOLT FLANGE 6X22 | 957010602208 |
|
